ADS8318 Series

Catalog

IC ADC 16BIT SAR 10VSON

Part	Voltage - Supply, Digital (Max)	Voltage - Supply, Digital (Min)	Voltage - Supply, Analog	Reference Type	Number of Inputs	Operating Temperature (Min)	Operating Temperature (Max)	Architecture	Ratio - ADC	Ratio - S/H	Number of Bits	Number of A/D Converters	Sampling Rate (Per Second)	Data Interface	Package Width	Package Name	Package Length	Input Type	Configuration	Package / Case	Mounting Type
Texas Instruments ADS8318IDRCTG4	5.5 V	2.375 V	5 V	External	1	-40 °C	85 °C	SAR	1	1	16 bits	1 count	500 kHz	SPI	3 mm	10-VSON	3 mm	Differential	S/H-ADC	10-VFDFN Exposed Pad	Surface Mount
Texas Instruments ADS8318IDRCT	5.5 V	2.375 V	5 V	External	1	-40 °C	85 °C	SAR	1	1	16 bits	1 count	500 kHz	SPI	3 mm	10-VSON	3 mm	Differential	S/H-ADC	10-VFDFN Exposed Pad	Surface Mount
Texas Instruments ADS8318IDGSTG4	5.5 V	2.375 V	5 V	External	1	-40 °C	85 °C	SAR	1	1	16 bits	1 count	500 kHz	SPI	3 mm	10-MSOP 10-TFSOP 10-VSSOP	0.118 in	Differential	S/H-ADC		Surface Mount
Texas Instruments ADS8318IBDRCR	5.5 V	2.375 V	5 V	External	1	-40 °C	85 °C	SAR	1	1	16 bits	1 count	500 kHz	SPI	3 mm	10-VSON	3 mm	Differential	S/H-ADC	10-VFDFN Exposed Pad	Surface Mount
Texas Instruments ADS8318IDRCR	5.5 V	2.375 V	5 V	External	1	-40 °C	85 °C	SAR	1	1	16 bits	1 count	500 kHz	SPI	3 mm	10-VSON	3 mm	Differential	S/H-ADC	10-VFDFN Exposed Pad	Surface Mount
Texas Instruments ADS8318IBDRCT	5.5 V	2.375 V	5 V	External	1	-40 °C	85 °C	SAR	1	1	16 bits	1 count	500 kHz	SPI	3 mm	10-VSON	3 mm	Differential	S/H-ADC	10-VFDFN Exposed Pad	Surface Mount
Texas Instruments ADS8318IDGST	5.5 V	2.375 V	5 V	External	1	-40 °C	85 °C	SAR	1	1	16 bits	1 count	500 kHz	SPI	3 mm	10-MSOP 10-TFSOP 10-VSSOP	0.118 in	Differential	S/H-ADC		Surface Mount
Texas Instruments ADS8318IBDGST	5.5 V	2.375 V	5 V	External	1	-40 °C	85 °C	SAR	1	1	16 bits	1 count	500 kHz	SPI	3 mm	10-MSOP 10-TFSOP 10-VSSOP	0.118 in	Differential	S/H-ADC		Surface Mount
Texas Instruments ADS8318IBDGSR	5.5 V	2.375 V	5 V	External	1	-40 °C	85 °C	SAR	1	1	16 bits	1 count	500 kHz	SPI	3 mm	10-MSOP 10-TFSOP 10-VSSOP	0.118 in	Differential	S/H-ADC		Surface Mount
Texas Instruments ADS8318IDGSR	5.5 V	2.375 V	5 V	External	1	-40 °C	85 °C	SAR	1	1	16 bits	1 count	500 kHz	SPI	3 mm	10-MSOP 10-TFSOP 10-VSSOP	0.118 in	Differential	S/H-ADC		Surface Mount
