LP38852 Series

Catalog

1.5-A, LOW-VIN (0.93-V), ADJUSTABLE ULTRA-LOW-DROPOUT VOLTAGE REGULATOR WITH ENABLE

Part	Voltage - Output (Max)	Protection Features	Voltage - Input (Max)	Package Leads	Package Name	Voltage Dropout (Max)	Output Type	Number of Regulators	Output Configuration	Operating Temperature (Max)	Operating Temperature (Min)	Current - Supply (Max)	Mounting Type	Current - Output	PSRR (Maximum)	PSRR (Minimum)	Voltage - Output (Min/Fixed)	Control Features	Current - Quiescent (Iq)	Package Width	Package Length	Package / Case
Texas Instruments LP38852S-ADJ/NOPB	1.8 V	Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO)	5.5 V	7 Leads	D2PAK TO-263 (DDPAK-7)	0.18 V	Adjustable	1	Positive	125 °C	-40 °C	9 mA	Surface Mount	1.5 A	80 dB	65 dB	0.8 V	Enable Soft Start	300 µA
Texas Instruments LP38852MRX-ADJ	1.8 V	Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO)	5.5 V		8-PowerSOIC 8-SO PowerPad	0.18 V	Adjustable	1	Positive	125 °C	-40 °C	9 mA	Surface Mount	1.5 A	80 dB	65 dB	0.8 V	Enable Soft Start	300 µA	3.9 mm	0.154 in
Texas Instruments LP38852S-ADJ	1.8 V	Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO)	5.5 V	7 Leads	D2PAK TO-263 (DDPAK-7)	0.18 V	Adjustable	1	Positive	125 °C	-40 °C	9 mA	Surface Mount	1.5 A	80 dB	65 dB	0.8 V	Enable Soft Start	300 µA
Texas Instruments LP38852T-ADJ	1.8 V	Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO)	5.5 V		TO-220-7	0.18 V	Adjustable	1	Positive	125 °C	-40 °C	9 mA	Through Hole	1.5 A	80 dB	65 dB	0.8 V	Enable Soft Start	300 µA			TO-220-7 Formed Leads
Texas Instruments LP38852MR-ADJ	1.8 V	Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO)	5.5 V		8-PowerSOIC 8-SO PowerPad	0.18 V	Adjustable	1	Positive	125 °C	-40 °C	9 mA	Surface Mount	1.5 A	80 dB	65 dB	0.8 V	Enable Soft Start	300 µA	3.9 mm	0.154 in
Texas Instruments LP38852SX-ADJ/NOPB	1.8 V	Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO)	5.5 V	7 Leads	D2PAK TO-263 (DDPAK-7)	0.18 V	Adjustable	1	Positive	125 °C	-40 °C	9 mA	Surface Mount	1.5 A	80 dB	65 dB	0.8 V	Enable Soft Start	300 µA
Texas Instruments LP38852MR-ADJ/NOPB	1.8 V	Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO)	5.5 V		8-PowerSOIC 8-SO PowerPad	0.18 V	Adjustable	1	Positive	125 °C	-40 °C	9 mA	Surface Mount	1.5 A	80 dB	65 dB	0.8 V	Enable Soft Start	300 µA	3.9 mm	0.154 in
Texas Instruments LP38852T-ADJ/NOPB	1.8 V	Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO)	5.5 V		TO-220-7	0.18 V	Adjustable	1	Positive	125 °C	-40 °C	9 mA	Through Hole	1.5 A	80 dB	65 dB	0.8 V	Enable Soft Start	300 µA			TO-220-7 Formed Leads
Texas Instruments LP38852SX-ADJ	1.8 V	Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO)	5.5 V	7 Leads	D2PAK TO-263 (DDPAK-7)	0.18 V	Adjustable	1	Positive	125 °C	-40 °C	9 mA	Surface Mount	1.5 A	80 dB	65 dB	0.8 V	Enable Soft Start	300 µA
Texas Instruments LP38852MRX-ADJ/NOPB	1.8 V	Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO)	5.5 V		8-PowerSOIC 8-SO PowerPad	0.18 V	Adjustable	1	Positive	125 °C	-40 °C	9 mA	Surface Mount	1.5 A	80 dB	65 dB	0.8 V	Enable Soft Start	300 µA	3.9 mm	0.154 in
