DRV8461 Series

Catalog

65-V, 3-A DUAL H-BRIDGE STEPPER MOTOR DRIVER WITH SMART TUNE, STALL DETECT AND AUTO-TORQUE

Part	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Package Width	Package Name	Package Length	Applications	Operating Temperature (Max)	Operating Temperature (Min)	Motor Type - Stepper	Motor Type - AC, DC	Technology	Step Resolution (Max)	Step Resolution (Min)	Function	Voltage - Load (Min)	Voltage - Load (Max)	Half-Bridge Count	Output Configuration	Mounting Type	Current - Output	Interface	Supplied Contents	Utilized IC / Part	Embedded	Primary Attributes	Type	Contents	Secondary Attributes
Texas Instruments DRV8461PWPR	65 V	4.5 V	4.4 mm	28-HTSSOP 28-PowerTSSOP	0.173 in	Printer	125 °C	-40 °C	Bipolar	Brushed DC Brushless DC (BLDC)	NMOS	1	0.00390625	Control and Power Stage Driver - Fully Integrated	4.5 V	65 V	2	Half Bridge	Surface Mount	3 A
Texas Instruments DRV8461DDWR	65 V	4.5 V	6.2 mm	44-HTSSOP 44-PowerTSSOP	0.244 in	Printer	125 °C	-40 °C	Bipolar		Power MOSFET	1	0.00390625	Control and Power Stage Driver - Fully Integrated	4.5 V	65 V	2	Half Bridge	Surface Mount	3 A	SPI Step/Direction
Texas Instruments DRV8461EVM														Driver Motor Controller								Board(s)	DRV8461	MCU Yes	Motors (Stepper)	Power Management	Board	On-Board LEDs Test Points
Texas Instruments DRV8461SPWPR	65 V	4.5 V	4.4 mm	28-HTSSOP 28-PowerTSSOP	0.173 in	Printer	125 °C	-40 °C	Bipolar	Brushed DC Brushless DC (BLDC)	NMOS	1	0.00390625	Control and Power Stage Driver - Fully Integrated	4.5 V	65 V	2	Half Bridge	Surface Mount	3 A	SPI
