LM3553 Series
Manufacturer: Texas Instruments
Beta
⌘K
EVAL BOARD FOR LM3553
| Part | Supplied Contents | Total Output Count | Output Type | Non-Isolated Output Count | Contents | Voltage - Input (Minimum) | Voltage - Input (Maximum) | Current - Output / Channel | Utilized IC / Part | Type | Package / Case | Package Width | Package Name | Package Length | Frequency | Voltage - Supply (Max) | Internal Switch(s) | Applications | Topology | Number of Outputs | Operating Temperature (Max) | Operating Temperature (Min) | Dimming | Mounting Type | Voltage - Supply (Min) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | Board(s) | 1 | Non-Isolated | 1 count | Board | 2.7 V | 5.5 V | 1.2 A | LM3553 | ||||||||||||||||
 Texas Instruments | 1.2 A | DC DC Regulator | 12-WFDFN Exposed Pad | 3 mm | 12-WSON | 3 mm | 1.2 MHz | 5.5 V | Yes | Backlight Camera Flash | Step-Up (Boost) | 1 | 85 °C | -30 °C | I2C | Surface Mount | 2.7 V | ||||||||
 Texas Instruments | 1.2 A | DC DC Regulator | 12-WFDFN Exposed Pad | 3 mm | 12-WSON | 3 mm | 1.2 MHz | 5.5 V | Yes | Backlight Camera Flash | Step-Up (Boost) | 1 | 85 °C | -30 °C | I2C | Surface Mount | 2.7 V |
