CSD13302 Series
Manufacturer: Texas Instruments
Beta
⌘K
12-V, N CHANNEL NEXFET™ POWER MOSFET, SINGLE WLP 1 MM X 1 MM, 17.1 MOHM
| Part | Mounting Type | Operating Temperature (Min) | Operating Temperature (Max) | Vgs(th) (Max) | Package / Case | Rds On (Max) | Gate Charge (Max) | Drive Voltage (Max Rds On) | Drive Voltage (Min Rds On) | Package Width | Package Name | Package Length | Power Dissipation (Max) | Vgs (Max) | Input Capacitance (Ciss) (Max) | FET Type | Current - Continuous Drain (Id) (Ta) | Drain to Source Voltage (Vdss) | Technology |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | Surface Mount | -55 °C | 150 °C | 1.3 V | 4-UFBGA DSBGA | 17.1 mOhm | 7.8 nC | 2.5 V | 4.5 V | 1 mm | 4-DSBGA | 1 mm | 1.8 W | 10 V | 862 pF | N-Channel | 1.6 A | 12 V | MOSFET (Metal Oxide) |
