OPA145 Series

Single, 5.5-MHz, high slew rate, low-noise, low-power, RRO precision JFET operational amplifier

Catalog

Single, 5.5-MHz, high slew rate, low-noise, low-power, RRO precision JFET operational amplifier

Part	Current - Input Bias	Package Name	Mounting Type	Package Width	Package Length	Amplifier Type	Operating Temperature (Max)	Operating Temperature (Min)	Voltage - Supply Span (Min)	Voltage - Supply Span (Max)	Number of Circuits	Output Type	Current - Output / Channel	Gain Bandwidth Product	Voltage - Input Offset	Current - Supply	Slew Rate
Texas Instruments OPA145IDGKR	2 pA	8-TSSOP 8-MSOP 8-VSSOP	Surface Mount	3 mm	0.118 in	J-FET	125 °C	-40 °C	4.5 V	36 V	1	Rail-to-Rail	20 mA	5.5 MHz	40 µV	445 µA	20 V/µs
Texas Instruments OPA145ID	2 pA	8-SOIC	Surface Mount	3.9 mm	0.154 in	J-FET	125 °C	-40 °C	4.5 V	36 V	1	Rail-to-Rail	20 mA	5.5 MHz	40 µV	445 µA	20 V/µs
Texas Instruments OPA145IDBVR	2 pA	SOT-23-5	Surface Mount			J-FET	125 °C	-40 °C	4.5 V	36 V	1	Rail-to-Rail	20 mA	5.5 MHz	40 µV	445 µA	20 V/µs
Texas Instruments OPA145IDR	2 pA	8-SOIC	Surface Mount	3.9 mm	0.154 in	J-FET	125 °C	-40 °C	4.5 V	36 V	1	Rail-to-Rail	20 mA	5.5 MHz	40 µV	445 µA	20 V/µs
Texas Instruments OPA145IDGKT	2 pA	8-TSSOP 8-MSOP 8-VSSOP	Surface Mount	3 mm	0.118 in	J-FET	125 °C	-40 °C	4.5 V	36 V	1	Rail-to-Rail	20 mA	5.5 MHz	40 µV	445 µA	20 V/µs
Texas Instruments OPA145IDBVT	2 pA	SOT-23-5	Surface Mount			J-FET	125 °C	-40 °C	4.5 V	36 V	1	Rail-to-Rail	20 mA	5.5 MHz	40 µV	445 µA	20 V/µs

Catalog

Single, 5.5-MHz, high slew rate, low-noise, low-power, RRO precision JFET operational amplifier

Description

The OPA145 and OPA2145 (OPAx145) devices are part of a family of low-power JFET input amplifier that have excellent drift, low current noise, and pico-ampere input bias current. These features make the OPAx145 an excellent choice for amplifying small signals from high-impedance sensors. The rail-to-rail output swing interfaces to modern, single-supply, precision, analog-to-digital converters (ADCs) and digital-to-analog converters (DACs). In addition, the input range that includes V– allows designers to simplify power management and take advantage of the single-supply, low-noise JFET architecture. The OPA145 and OPA2145 (OPAx145) devices are part of a family of low-power JFET input amplifier that have excellent drift, low current noise, and pico-ampere input bias current. These features make the OPAx145 an excellent choice for amplifying small signals from high-impedance sensors. The rail-to-rail output swing interfaces to modern, single-supply, precision, analog-to-digital converters (ADCs) and digital-to-analog converters (DACs). In addition, the input range that includes V– allows designers to simplify power management and take advantage of the single-supply, low-noise JFET architecture.
