LMK61E08 Series

Catalog

OSCILLATOR XO ±25PPM HCSL/LVDS/LVPECL 55% 3.3V 6-PIN QFM SMD T/R

Part	Current - Supply (Disable) (Max)	Current - Supply (Max)	Output	Base Resonator	Voltage - Supply	Frequency Stability (Total)	Type	Function	Package / Case	Operating Temperature (Min)	Operating Temperature (Max)	Package Length	Package Name	Package Width	Programmable Type	Height - Seated (Max)	Size / Dimension Width	Size / Dimension Length	Mounting Type	Available Frequency Range (Minimum)	Available Frequency Range (Maximum)
Texas Instruments LMK61E08-SIAT	120 mA	208 mA	HCSL LVDS LVPECL	Silicon	3.3 V	25 ppm	VCXO	Disable Enable	6-SMD Module	-40 °C	85 °C	7 mm	6-QFM	5 mm	Factory-Configured	0.045 in	0.197 in	0.276 in	Surface Mount	10 MHz	1 GHz
Texas Instruments LMK61E08-SIAR	120 mA	208 mA	HCSL LVDS LVPECL	Silicon	3.3 V	25 ppm	VCXO	Disable Enable	6-SMD Module	-40 °C	85 °C	7 mm	6-QFM	5 mm	Factory-Configured	0.045 in	0.197 in	0.276 in	Surface Mount	10 MHz	1 GHz
