LM9071 Series

Catalog

IC REG LIN 5V 250MA DDPAK/TO263

Part	Protection Features	Number of Regulators	Voltage Dropout (Max)	Current - Output	Current - Quiescent (Iq)	Package Name	Package Leads	Current - Supply (Max)	Voltage - Input (Max)	Operating Temperature (Max)	Operating Temperature (Min)	Mounting Type	Output Configuration	Voltage - Output (Min/Fixed)	PSRR	Output Type	Package / Case
Texas Instruments LM9071S	Over Temperature Over Voltage Reverse Polarity Short Circuit	1	0.8 V	250 mA	4 mA	D2PAK TO-263 (DDPAK-5)	5 Leads	50 mA	26 V	125 °C	-40 °C	Surface Mount	Positive	5 V	60 dB	Fixed
Texas Instruments LM9071S/NOPB	Over Temperature Over Voltage Reverse Polarity Short Circuit	1	0.8 V	250 mA	4 mA	D2PAK TO-263 (DDPAK-5)	5 Leads	50 mA	26 V	125 °C	-40 °C	Surface Mount	Positive	5 V	60 dB	Fixed
Texas Instruments LM9071T/NOPB	Over Temperature Over Voltage Reverse Polarity Short Circuit	1	0.8 V	250 mA	4 mA	TO-220-5		50 mA	26 V	125 °C	-40 °C	Through Hole	Positive	5 V	60 dB	Fixed	TO-220-5
Texas Instruments LM9071SX	Over Temperature Over Voltage Reverse Polarity Short Circuit	1	0.8 V	250 mA	4 mA	D2PAK TO-263 (DDPAK-5)	5 Leads	50 mA	26 V	125 °C	-40 °C	Surface Mount	Positive	5 V	60 dB	Fixed
Texas Instruments LM9071SX/NOPB	Over Temperature Over Voltage Reverse Polarity Short Circuit	1	0.8 V	250 mA	4 mA	D2PAK TO-263 (DDPAK-5)	5 Leads	50 mA	26 V	125 °C	-40 °C	Surface Mount	Positive	5 V	60 dB	Fixed
