ADS8472 Series

Catalog

IC ADC 16BIT SAR 48VQFN

Part	Voltage - Supply, Analog	Configuration	Architecture	Mounting Type	Input Type	Number of Inputs	Package / Case	Ratio - ADC	Ratio - S/H	Operating Temperature (Min)	Operating Temperature (Max)	Voltage - Supply, Digital (Min)	Voltage - Supply, Digital (Max)	Data Interface	Reference Type	Number of A/D Converters	Number of Bits	Package Length	Package Name	Package Width	Sampling Rate (Per Second)
Texas Instruments ADS8472IRGZR	5 V	S/H-ADC	SAR	Surface Mount	Differential	1	48-VFQFN Exposed Pad	1	1	-40 °C	85 °C	2.7 V	5.25 V	Parallel	External Internal	1 count	16 bits	7 mm	48-VQFN	7 mm	1 MHz
Texas Instruments ADS8472IBRGZR	5 V	S/H-ADC	SAR	Surface Mount	Differential	1	48-VFQFN Exposed Pad	1	1	-40 °C	85 °C	2.7 V	5.25 V	Parallel	External Internal	1 count	16 bits	7 mm	48-VQFN	7 mm	1 MHz
Texas Instruments ADS8472IRGZT	5 V	S/H-ADC	SAR	Surface Mount	Differential	1	48-VFQFN Exposed Pad	1	1	-40 °C	85 °C	2.7 V	5.25 V	Parallel	External Internal	1 count	16 bits	7 mm	48-VQFN	7 mm	1 MHz
Texas Instruments ADS8472IBRGZT	5 V	S/H-ADC	SAR	Surface Mount	Differential	1	48-VFQFN Exposed Pad	1	1	-40 °C	85 °C	2.7 V	5.25 V	Parallel	External Internal	1 count	16 bits	7 mm	48-VQFN	7 mm	1 MHz
Texas Instruments ADS8472IRGZTG4	5 V	S/H-ADC	SAR	Surface Mount	Differential	1	48-VFQFN Exposed Pad	1	1	-40 °C	85 °C	2.7 V	5.25 V	Parallel	External Internal	1 count	16 bits	7 mm	48-VQFN	7 mm	1 MHz
