ADS7818 Series
Manufacturer: Texas Instruments
Beta
⌘K
1-CHANNEL SINGLE ADC SAR 500KSPS 12-BIT SERIAL 8-PIN VSSOP T/R
| Part | Operating Temperature (Min) | Operating Temperature (Max) | Number of Inputs | Sampling Rate (Per Second) | Configuration | Number of A/D Converters | Ratio - ADC | Ratio - S/H | Package Name | Data Interface | Number of Bits | Package Width | Package Length | Voltage - Supply, Analog | Architecture | Reference Type | Input Type | Voltage - Supply, Digital | Mounting Type | Supplied Contents | Power (Typ) | Input Voltage (Min) | Input Voltage (Max) | Utilized IC / Part | Contents |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | -40 °C | 85 °C | 1 | 500 kHz | S/H-ADC | 1 count | 1 | 1 | 8-TSSOP 8-MSOP 8-VSSOP | SPI | 12 bits | 3 mm | 0.118 in | 5 V | SAR | Internal | Differential | 5 V | Surface Mount | ||||||
 Texas Instruments | -40 °C | 85 °C | 1 | 500 kHz | S/H-ADC | 1 count | 1 | 1 | 8-TSSOP 8-MSOP 8-VSSOP | SPI | 12 bits | 3 mm | 0.118 in | 5 V | SAR | Internal | Differential | 5 V | Surface Mount | ||||||
Texas Instruments | -40 °C | 85 °C | 1 | 500 kHz | S/H-ADC | 1 count | 1 | 1 | 8-TSSOP 8-MSOP 8-VSSOP | SPI | 12 bits | 3 mm | 0.118 in | 5 V | SAR | Internal | Differential | 5 V | Surface Mount | ||||||
Texas Instruments | -40 °C | 85 °C | 1 | 500 kHz | S/H-ADC | 1 count | 1 | 1 | 8-TSSOP 8-MSOP 8-VSSOP | SPI | 12 bits | 3 mm | 0.118 in | 5 V | SAR | Internal | Differential | 5 V | Surface Mount | ||||||
 Texas Instruments | -40 °C | 85 °C | 1 | 500 kHz | S/H-ADC | 1 count | 1 | 1 | 8-DIP 8-PDIP | SPI | 12 bits | 7.62 mm | 0.3 in | 5 V | SAR | Internal | Differential | 5 V | Through Hole | ||||||
Texas Instruments | -40 °C | 85 °C | 1 | 500 kHz | S/H-ADC | 1 count | 1 | 1 | 8-TSSOP 8-MSOP 8-VSSOP | SPI | 12 bits | 3 mm | 0.118 in | 5 V | SAR | Internal | Differential | 5 V | Surface Mount | ||||||
 Texas Instruments | -40 °C | 85 °C | 1 | 500 kHz | S/H-ADC | 1 count | 1 | 1 | 8-TSSOP 8-MSOP 8-VSSOP | SPI | 12 bits | 3 mm | 0.118 in | 5 V | SAR | Internal | Differential | 5 V | Surface Mount | ||||||
 Texas Instruments | 500 kHz | 1 count | Serial | 12 bits | Board(s) | 11 mW | 0 mV | 5 V | ADS7818 | Board | |||||||||||||||
Texas Instruments | -40 °C | 85 °C | 1 | 500 kHz | S/H-ADC | 1 count | 1 | 1 | 8-TSSOP 8-MSOP 8-VSSOP | SPI | 12 bits | 3 mm | 0.118 in | 5 V | SAR | Internal | Differential | 5 V | Surface Mount | ||||||
 Texas Instruments | -40 °C | 85 °C | 1 | 500 kHz | S/H-ADC | 1 count | 1 | 1 | 8-DIP 8-PDIP | SPI | 12 bits | 7.62 mm | 0.3 in | 5 V | SAR | Internal | Differential | 5 V | Through Hole |
