AD9094 Series

Catalog

8-BIT, 1 GSPS, JESD204B, QUAD ANALOG-TO-DIGITAL CONVERTER

Part	Mounting Type	Input Type	Reference Type	Number of A/D Converters	Number of Inputs	Configuration	Voltage - Supply, Analog (Range 2 Min)	Voltage - Supply, Analog (Range 1 Min)	Voltage - Supply, Analog (Range 3 Min)	Voltage - Supply, Analog (Range 2 Max)	Voltage - Supply, Analog (Range 1 Max)	Voltage - Supply, Analog (Range 3 Max)	Package Length	Package Name	Package Width	Ratio - ADC	Ratio - S/H	Number of Bits	Sampling Rate (Per Second)	Data Interface	Voltage - Supply, Digital (Range 2) Maximum	Voltage - Supply, Digital (Range 2) Minimum	Voltage - Supply, Digital (Range 1) Maximum	Voltage - Supply, Digital (Range 1) Minimum	Architecture	Operating Temperature (Min)	Operating Temperature (Max)	Package / Case	Supplied Contents	Contents	Input Voltage (Value)	Power (Typ)	Utilized IC / Part
Analog Devices Inc./Maxim Integrated AD9094BCPZRL7-1000	Surface Mount	Differential	External Internal	4 count	4	S/H-ADC	1.71 V	0.95 V	2.44 V	1.89 V	1 V	2.56 V	10 mm	72-LFCSP-VQ	10 mm	1	1	8 bits	1 GHz	JESD204B Parallel SPI	1.89 V	1.71 V	1 V	0.95 V	Pipelined	-40 °C	105 °C	72-VFQFN Exposed Pad CSP
Analog Devices Inc./Maxim Integrated AD9094-1000EBZ				4 count														8 bits	1 GHz	JESD204B Parallel Serial SPI									Board(s)	Board	1.8 Vpp	435 mW	AD9094
Analog Devices Inc./Maxim Integrated AD9094BCPZ-1000	Surface Mount	Differential	External Internal	4 count	4	S/H-ADC	1.71 V	0.95 V	2.44 V	1.89 V	1 V	2.56 V	10 mm	72-LFCSP-VQ	10 mm	1	1	8 bits	1 GHz	JESD204B Parallel SPI	1.89 V	1.71 V	1 V	0.95 V	Pipelined	-40 °C	105 °C	72-VFQFN Exposed Pad CSP
