THS7314 Series

Catalog

3-CHANNEL SDTV VIDEO AMP WITH 5TH ORDER FILTER AND 6-DB GAIN

Part	Output Type	Number of Circuits	Applications	Package Name	Current - Output / Channel	Mounting Type	Package Length	Package Width	Supply Configuration	Voltage - Supply (Single) Minimum	Voltage - Supply (Single) Maximum	Current - Supply	Supplied Contents	Contents	Type	Secondary Attributes	Primary Attributes	Embedded	Function	Utilized IC / Part
Texas Instruments THS7314DR	Rail-to-Rail	3	Buffer	8-SOIC	70 mA	Surface Mount	0.154 in	3.9 mm	Dual Single	2.85 V	5.5 V	16 mA
Texas Instruments THS7314DG4	Rail-to-Rail	3	Buffer	8-SOIC	70 mA	Surface Mount	0.154 in	3.9 mm	Dual Single	2.85 V	5.5 V	16 mA
Texas Instruments THS7314D	Rail-to-Rail	3	Buffer	8-SOIC	70 mA	Surface Mount	0.154 in	3.9 mm	Dual Single	2.85 V	5.5 V	16 mA
Texas Instruments THS7314EVM													Board(s)	Board	Video	AC- DC-Coupled Inputs and Outputs	Buffer with Filter Gain 6dB	No	Amplifier Triple	THS7314
