ADG5243F Series

Catalog

USER DEFINED FAULT PROTECTION AND DETECTION, 0.8 PC QINJ, TRIPLE SPDT

Part	Channel-to-Channel Matching (ΔRon)	Charge Injection	Switch Time Ton (Max)	Switch Time Toff (Max)	Package Length	Package Name	Package Width	Current - Leakage (Max)	On-State Resistance (Max)	-3db Bandwidth	Crosstalk	Switch Circuit Type	Voltage - Supply, Single (V+) (Maximum)	Voltage - Supply, Single (V+) (Minimum)	Multiplexer Inputs	Demultiplexer Outputs	Operating Temperature (Max)	Operating Temperature (Min)	Voltage - Supply, Dual (Minimum)	Voltage - Supply, Dual (Maximum)	Voltage - Supply, Dual (Nominal)	Mounting Type	Number of Circuits
Analog Devices Inc./Maxim Integrated ADG5243FBRUZ	3 Ohm	-1.4 pC	215 ns	85 ns	0.173 in	20-TSSOP	4.4 mm	1 nA	335 Ohm	350 MHz	-85 dB	SPDT	44 V	8 V	2	1	125 °C	-40 °C	-5 V	22 V	5 V	Surface Mount	3
Analog Devices Inc./Maxim Integrated ADG5243FBRUZ-RL7	3 Ohm	-1.4 pC	215 ns	85 ns	0.173 in	20-TSSOP	4.4 mm	1 nA	335 Ohm	350 MHz	-85 dB	SPDT	44 V	8 V	2	1	125 °C	-40 °C	-5 V	22 V	5 V	Surface Mount	3
