AD9628 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

12-BIT, 125/105 MSPS, 1.8 V DUAL ANALOG-TO-DIGITAL CONVERTER

Part	Features	Input Type	Ratio - ADC	Ratio - S/H	Package Length	Package Name	Package Width	Reference Type	Voltage - Supply, Analog (Max)	Voltage - Supply, Analog (Min)	Package / Case	Configuration	Voltage - Supply, Digital (Min)	Voltage - Supply, Digital (Max)	Number of Bits	Operating Temperature (Min)	Operating Temperature (Max)	Architecture	Mounting Type	Data Interface	Number of A/D Converters	Sampling Rate (Per Second)	Number of Inputs	Utilized IC / Part	Contents
Analog Devices Inc./Maxim Integrated AD9628BCPZRL7-105	Simultaneous Sampling	Differential Single Ended	1	1	9 mm	64-LFCSP-VQ	9 mm	External Internal	1.9 V	1.7 V	64-VFQFN Exposed Pad CSP	S/H-ADC	1.7 V	1.9 V	12 bits	-40 °C	85 °C	Pipelined	Surface Mount	LVDS - Parallel	2 count	105 MHz	2
Analog Devices Inc./Maxim Integrated AD9628BCPZ-105	Simultaneous Sampling	Differential Single Ended	1	1	9 mm	64-LFCSP-VQ	9 mm	External Internal	1.9 V	1.7 V	64-VFQFN Exposed Pad CSP	S/H-ADC	1.7 V	1.9 V	12 bits	-40 °C	85 °C	Pipelined	Surface Mount	LVDS - Parallel	2 count	105 MHz	2
Analog Devices Inc./Maxim Integrated AD9628BCPZRL7-125	Simultaneous Sampling	Differential Single Ended	1	1	9 mm	64-LFCSP-VQ	9 mm	External Internal	1.9 V	1.7 V	64-VFQFN Exposed Pad CSP	S/H-ADC	1.7 V	1.9 V	12 bits	-40 °C	85 °C	Pipelined	Surface Mount	LVDS - Parallel	2 count	125 MHz	2
Analog Devices Inc./Maxim Integrated AD9628-125EBZ															12 bits					Serial	2 count	125 MHz		AD9628	Board
Analog Devices Inc./Maxim Integrated AD9628BCPZ-125	Simultaneous Sampling	Differential Single Ended	1	1	9 mm	64-LFCSP-VQ	9 mm	External Internal	1.9 V	1.7 V	64-VFQFN Exposed Pad CSP	S/H-ADC	1.7 V	1.9 V	12 bits	-40 °C	85 °C	Pipelined	Surface Mount	LVDS - Parallel	2 count	125 MHz	2
