LM5012 Series

Catalog

AUTOMOTIVE, 6-V TO 100-V INPUT, 2.5-A NON-SYNCHRONOUS BUCK DC/DC CONVERTER

Part	Frequency - Switching (Max)	Voltage - Input (Min)	Operating Temperature (Min)	Operating Temperature (Max)	Topology	Synchronous Rectifier	Voltage - Output (Min/Fixed)	Voltage - Input (Max)	Number of Outputs	Function	Output Type	Current - Output	Grade	Package Name	Output Configuration	Qualification	Mounting Type	Package Width	Package Length	Voltage - Output (Max)
Texas Instruments LM5012QDDARQ1	1 MHz	6 V	-40 °C	150 °C	Buck	No	1.2 V	100 V p-p	1	Step-Down	Adjustable	2.5 A	Automotive	8-PowerSOIC 8-SO PowerPad	Positive	AEC-Q100	Surface Mount	3.9 mm	0.154 in	100 V
Texas Instruments LM5012DDAR	1 MHz	6 V	-40 °C	150 °C	Buck	No	1.2 V	100 V p-p	1	Step-Down	Adjustable	2.5 A		8-PowerSOIC 8-SO PowerPad	Positive		Surface Mount	3.9 mm	0.154 in	100 V
