LM2591 Series
Manufacturer: Texas Instruments
Beta
⌘K
SIMPLE SWITCHER POWER CONVERTER 150 KHZ 1A STEP-DOWN VOLTAGE REGULATOR
| Part | Function | Package / Case | Output Type | Output Configuration | Mounting Type | Number of Outputs | Frequency - Switching | Current - Output | Voltage - Output (Min/Fixed) | Voltage - Input (Min) | Package Name | Synchronous Rectifier | Voltage - Input (Max) | Operating Temperature (Max) | Operating Temperature (Min) | Topology | Package Leads | Voltage - Output (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | Step-Down | TO-220-5 Formed Leads | Fixed | Positive | Through Hole | 1 | 150 kHz | 1 A | 5 V | 4.5 V | TO-220-5 | No | 60 V | 125 °C | -40 °C | Buck | ||
 Texas Instruments | Step-Down | Fixed | Positive | Surface Mount | 1 | 150 kHz | 1 A | 3.3 V | 4.5 V | D2PAK TO-263 (DDPAK-5) | No | 60 V | 125 °C | -40 °C | Buck | 5 Leads | ||
 Texas Instruments | Step-Down | TO-220-5 Formed Leads | Fixed | Positive | Through Hole | 1 | 150 kHz | 1 A | 3.3 V | 4.5 V | TO-220-5 | No | 60 V | 125 °C | -40 °C | Buck | ||
 Texas Instruments | Step-Down | Fixed | Positive | Surface Mount | 1 | 150 kHz | 1 A | 5 V | 4.5 V | D2PAK TO-263 (DDPAK-5) | No | 60 V | 125 °C | -40 °C | Buck | 5 Leads | ||
 Texas Instruments | Step-Down | Fixed | Positive | Surface Mount | 1 | 150 kHz | 1 A | 3.3 V | 4.5 V | D2PAK TO-263 (DDPAK-5) | No | 60 V | 125 °C | -40 °C | Buck | 5 Leads | ||
Texas Instruments | Step-Down | Fixed | Positive | Surface Mount | 1 | 150 kHz | 1 A | 3.3 V | 4.5 V | D2PAK TO-263 (DDPAK-5) | No | 60 V | 125 °C | -40 °C | Buck | 5 Leads | ||
 Texas Instruments | Step-Down | TO-220-5 Formed Leads | Adjustable | Positive | Through Hole | 1 | 150 kHz | 1 A | 1.2 V | 4.5 V | TO-220-5 | No | 60 V | 125 °C | -40 °C | Buck | 57 V | |
Texas Instruments | Step-Down | TO-220-5 Formed Leads | Adjustable | Positive | Through Hole | 1 | 150 kHz | 1 A | 1.2 V | 4.5 V | TO-220-5 | No | 60 V | 125 °C | -40 °C | Buck | 57 V | |
Texas Instruments | Step-Down | TO-220-5 Formed Leads | Adjustable | Positive | Through Hole | 1 | 150 kHz | 1 A | 1.2 V | 4.5 V | TO-220-5 | No | 60 V | 125 °C | -40 °C | Buck | 57 V | |
 Texas Instruments | Step-Down | Adjustable | Positive | Surface Mount | 1 | 150 kHz | 1 A | 1.2 V | 4.5 V | D2PAK TO-263 (DDPAK-5) | No | 60 V | 125 °C | -40 °C | Buck | 5 Leads | 57 V |
