C4D20120 Series
Manufacturer: Wolfspeed, Inc.
Beta
⌘K
DIODE SCHOTTKY SIC 1.2KV 68A 3-PIN(3+TAB) TO-247 TUBE
| Part | Current - Average Rectified (Io) (per Diode) | Package / Case | Current - Reverse Leakage | Reverse Recovery Time (trr) | Operating Temperature - Junction (Max) | Operating Temperature - Junction (Min) | Mounting Type | Voltage - Forward (Vf) (Max) | Package Name | Diode Pair Count | Diode Configuration | Voltage - DC Reverse (Vr) (Max) | Speed - Fast Recovery (Minimum) | Speed | Speed - Recovery Current | Technology | Current - Average Rectified (Io) | Capacitance |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Wolfspeed, Inc. | 16 A 34 A | TO-247-3 | 200 µA | 0 ns | 175 °C | -55 °C | Through Hole | 1.8 V | TO-247-3 | 1 pair | Common Cathode | 1200 V | 500 mA | No Recovery Time | 500 mA 500 mA | SiC (Silicon Carbide) Schottky | ||
 Wolfspeed, Inc. | TO-247-2 | 200 µA | 0 ns | 175 °C | -55 °C | Through Hole | 1.8 V | TO-247-2 | 1200 V | 500 mA | No Recovery Time | 500 mA 500 mA | SiC (Silicon Carbide) Schottky | 54 A | 1500 pF | |||
 Wolfspeed, Inc. | TO-220-2 | 200 µA | 0 ns | 175 °C | -55 °C | Through Hole | 1.8 V | TO-220-2 | 1200 V | 500 mA | No Recovery Time | 500 mA 500 mA | SiC (Silicon Carbide) Schottky | 54.5 A | 1500 pF |
