OPA2836 Series

Automotive, Dual, Very Low Power, Rail to Rail output, VFB Op Amp

Catalog

Automotive, Dual, Very Low Power, Rail to Rail output, VFB Op Amp

Part	Current - Output / Channel	Supplied Contents	Output Type	Board Type	-3db Bandwidth	Current - Supply (Main IC)	Contents	Voltage - Supply (Single) Maximum	Supply Configuration	Voltage - Supply (Dual) Maximum (Magnitude)	Voltage - Supply (Dual) Minimum (Magnitude)	Voltage - Supply (Single) Minimum	Utilized IC / Part	Slew Rate	Channels per IC (Dual)	Channels per IC (Type)	Channels per IC (Count)	Amplifier Type	Gain Bandwidth Product	Voltage - Supply Span (Max)	Voltage - Input Offset	Package Name	Package Length	Package Width	Package / Case	Mounting Type	Current - Input Bias	Current - Supply	Operating Temperature (Max)	Operating Temperature (Min)	Voltage - Supply Span (Min)	Number of Circuits	Grade	Qualification
Texas Instruments OPA2836IDGSEVM	50 mA	Board(s)	Rail-to-Rail Single-Ended	Fully Populated	205 MHz	0.001 mA	Board	5.5 V	Dual Single	2.75 V	1.25 V	2.5 V	OPA2836	580 V/µs	2	Dual	2	Voltage Feedback	118 MHz
Texas Instruments OPA2836IRUNR	50 mA		Differential Rail-to-Rail		205 MHz									580 V/µs				Voltage Feedback	118 MHz	5.5 V	65 µV	10-WQFN	2 mm	2 mm	10-WFQFN	Surface Mount	650 nA	1 mA	125 °C	-40 °C	2.5 V	2
Texas Instruments OPA2836IRUNT	50 mA		Differential Rail-to-Rail		205 MHz									580 V/µs				Voltage Feedback	118 MHz	5.5 V	65 µV	10-WQFN	2 mm	2 mm	10-WFQFN	Surface Mount	650 nA	1 mA	125 °C	-40 °C	2.5 V	2
Texas Instruments OPA2836IDR	50 mA		Differential Rail-to-Rail		205 MHz									560 V/µs				Voltage Feedback	118 MHz	5.5 V	65 µV	8-SOIC	0.154 in	3.9 mm		Surface Mount	650 nA	1 mA	125 °C	-40 °C	2.5 V	2
Texas Instruments OPA2836IRMCT	50 mA		Differential Rail-to-Rail		205 MHz									580 V/µs				Voltage Feedback	118 MHz	5.5 V	65 µV	10-UQFN	2 mm	2 mm	10-UFQFN	Surface Mount	650 nA	1 mA	85 °C	-40 °C	2.5 V	2
Texas Instruments OPA2836IDGS	50 mA		Differential Rail-to-Rail		205 MHz									560 V/µs				Voltage Feedback	118 MHz	5.5 V	65 µV	10-MSOP 10-TFSOP 10-VSSOP	0.118 in	3 mm		Surface Mount	650 nA	1 mA	125 °C	-40 °C	2.5 V	2
Texas Instruments OPA2836ID	50 mA		Differential Rail-to-Rail		205 MHz									560 V/µs				Voltage Feedback	118 MHz	5.5 V	65 µV	8-SOIC	0.154 in	3.9 mm		Surface Mount	650 nA	1 mA	125 °C	-40 °C	2.5 V	2
Texas Instruments OPA2836QDGKRQ1	50 mA		Differential Rail-to-Rail		205 MHz									560 V/µs				Voltage Feedback	118 MHz	5.5 V	65 µV	8-TSSOP 8-MSOP 8-VSSOP	0.118 in	3 mm		Surface Mount	650 nA	950 µA	125 °C	-40 °C	2.5 V	2	Automotive	AEC-Q100
Texas Instruments OPA2836IDGSR	50 mA		Differential Rail-to-Rail		205 MHz									560 V/µs				Voltage Feedback	118 MHz	5.5 V	65 µV	10-MSOP 10-TFSOP 10-VSSOP	0.118 in	3 mm		Surface Mount	650 nA	1 mA	125 °C	-40 °C	2.5 V	2

Catalog

Automotive, Dual, Very Low Power, Rail to Rail output, VFB Op Amp

Description

The OPA2836-Q1 device is a dual-channel, ultra-low power, rail-to-rail output, negative-rail input, voltage-feedback operational amplifier designed to operate over a power-supply range of 2.5 V to 5.5 V (single supply), or ±1.25 V to ±2.75 V (dual supply). Consuming only 1 mA per channel with a unity-gain bandwidth of 205 MHz, this amplifier sets an industry-leading, power-to-performance ratio for rail-to-rail amplifiers. For battery-powered, portable applications where power is a key importance, the low-power consumption and high-frequency performance of the OPA2836-Q1 offers designers performance-versus-power that is not attainable in other devices. The OPA2836-Q1 is characterized for operation over the extended industrial temperature range of –40°C to +125°C. The OPA2836-Q1 device is a dual-channel, ultra-low power, rail-to-rail output, negative-rail input, voltage-feedback operational amplifier designed to operate over a power-supply range of 2.5 V to 5.5 V (single supply), or ±1.25 V to ±2.75 V (dual supply). Consuming only 1 mA per channel with a unity-gain bandwidth of 205 MHz, this amplifier sets an industry-leading, power-to-performance ratio for rail-to-rail amplifiers. For battery-powered, portable applications where power is a key importance, the low-power consumption and high-frequency performance of the OPA2836-Q1 offers designers performance-versus-power that is not attainable in other devices. The OPA2836-Q1 is characterized for operation over the extended industrial temperature range of –40°C to +125°C.
