SI1013 Series
Manufacturer: Vishay Dale
Beta
⌘K
MOSFET P-CH 20V 350MA SC89-3
| Part | Operating Temperature (Min) | Operating Temperature (Max) | Current - Continuous Drain (Id) (Ta) | FET Type | Rds On (Max) | Mounting Type | Package Name | Gate Charge (Max) | Drive Voltage (Min Rds On) | Drive Voltage (Max Rds On) | Vgs(th) (Max) | Vgs (Max) | Package / Case | Technology | Drain to Source Voltage (Vdss) | Power Dissipation (Max) | Drive Voltage (Max Rds On, Min Rds On) | Input Capacitance (Ciss) (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Vishay Dale | -55 °C | 150 °C | 350 mA | P-Channel | 1.2 Ohm | Surface Mount | SC-89-3 | 1.5 nC | 4.5 V | 1.8 V | 450 mV | 6 V | SC-89 SOT-490 | MOSFET (Metal Oxide) | 20 V | 250 mW | ||
Vishay Dale | -55 °C | 150 °C | 450 mA | P-Channel | 760 mOhm | Surface Mount | SC-89-3 | 2.5 nC | 1 V | 8 V | SC-89 SOT-490 | MOSFET (Metal Oxide) | 20 V | 190 mW | 4.5 V | 45 pF | ||
 Vishay Dale | -55 °C | 150 °C | 350 mA | P-Channel | 1.2 Ohm | Surface Mount | SC-75A | 1.5 nC | 4.5 V | 1.8 V | 450 mV | 6 V | SC-75 SOT-416 | MOSFET (Metal Oxide) | 20 V | 150 mW | ||
 Vishay Dale | -55 °C | 150 °C | 350 mA | P-Channel | 1.2 Ohm | Surface Mount | SC-89-3 | 1.5 nC | 4.5 V | 1.8 V | 450 mV | 6 V | SC-89 SOT-490 | MOSFET (Metal Oxide) | 20 V | 250 mW |
