TM4C123GE6PZ Series

32-bit Arm Cortex-M4F based MCU with 80-MHz, 128-kb Flash, 32-kb RAM, 2x CAN, RTC, USB, 100-pin LQFP

Catalog

32-bit Arm Cortex-M4F based MCU with 80-MHz, 128-kb Flash, 32-kb RAM, 2x CAN, RTC, USB, 100-pin LQFP

Part	Peripherals	Mounting Type	Program Memory Depth (128KB)	Program Memory Size	Program Memory Width (128KB)	Oscillator Type	Voltage - Supply (Vcc/Vdd) Maximum	Voltage - Supply (Vcc/Vdd) Minimum	Program Memory Type	EEPROM Size (Depth)	EEPROM Size (Width)	Connectivity	Speed	A/D Resolution (bits)	A/D Channels	Package / Case	Core Processor	Number of I/O	Package Width	Package Name	Package Length	Core Size (Bit Width)	Operating Temperature (Max)	Operating Temperature (Min)	RAM Size Width	RAM Size Depth
Texas Instruments TM4C123GE6PZI7R	Brown-out Detect DMA Motion PWM POR Reset WDT	Surface Mount	128 K	128KB	8	Internal	3.63 V	1.08 V	FLASH	2 K	8 bit	CANbus I2C IrDA Microwire QEI SPI SSI UART USART USB OTG	80 MHz	12 bit	22 count	100-LQFP	ARM® Cortex®-M4F	69	14 mm	100-LQFP	14 mm	32 Bit	85 °C	-40 °C	8 bit	32 K

Catalog

32-bit Arm Cortex-M4F based MCU with 80-MHz, 128-kb Flash, 32-kb RAM, 2x CAN, RTC, USB, 100-pin LQFP

Description

The TM4C123GE6PZ microcontroller is targeted for industrial applications, including remote monitoring, electronic point-of-sale machines, test and measurement equipment, network appliances and switches, factory automation, HVAC and building control, gaming equipment, motion control, transportation, and fire and security. The TM4C123GE6PZ microcontroller is targeted for industrial applications, including remote monitoring, electronic point-of-sale machines, test and measurement equipment, network appliances and switches, factory automation, HVAC and building control, gaming equipment, motion control, transportation, and fire and security.
