AD8314 Series

Catalog

RF DETECTOR / CONTROLLER, 100 MHZTO 2.7 GHZ, 45DB

Part	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Frequency Range 1 (Min)	Frequency Range 1 (Max)	RF Type	Package Name	Current - Supply	Input Level (Min)	Input Level (Max)	Mounting Type	Package Width	Package Length	For Use With/Related Products	Supplied Contents	Type	Utilized IC / Part	Contents	Package / Case
Analog Devices Inc./Maxim Integrated AD8314ARMZ-REEL	5.5 V	2.7 V	100 MHz	2.7 GHz	CDMA Cellular GSM TDMA	8-MSOP 8-TSSOP 8-MSOP	5.7 mA	-45 dBm	0 dBm	Surface Mount	3 mm	0.118 in
Analog Devices Inc./Maxim Integrated AD8314-EVAL													AD8314	Board(s)	RF Log Detector/Controller	AD8314	Board
Analog Devices Inc./Maxim Integrated AD8314ARM	5.5 V	2.7 V	100 MHz	2.7 GHz	CDMA Cellular GSM TDMA	8-MSOP 8-TSSOP 8-MSOP	5.7 mA	-45 dBm	0 dBm	Surface Mount	3 mm	0.118 in
Analog Devices Inc./Maxim Integrated AD8314ARMZ	5.5 V	2.7 V	100 MHz	2.7 GHz	CDMA Cellular GSM TDMA	8-MSOP 8-TSSOP 8-MSOP	5.7 mA	-45 dBm	0 dBm	Surface Mount	3 mm	0.118 in
Analog Devices Inc./Maxim Integrated AD8314ACP-EVALZ			100 MHz	2.7 GHz									AD8314	Board(s)	RF Log Detector/Controller	AD8314	Board
Analog Devices Inc./Maxim Integrated AD8314ARMZ-REEL7	5.5 V	2.7 V	100 MHz	2.7 GHz	CDMA Cellular GSM TDMA	8-MSOP 8-TSSOP 8-MSOP	5.7 mA	-45 dBm	0 dBm	Surface Mount	3 mm	0.118 in
Analog Devices Inc./Maxim Integrated AD8314ACPZ-RL7	5.5 V	2.7 V	100 MHz	2.7 GHz	CDMA Cellular GSM TDMA	8-LFCSP-VD	5.7 mA	-45 dBm	0 dBm	Surface Mount	2 mm	3 mm						8-VFDFN Exposed Pad CSP
Analog Devices Inc./Maxim Integrated AD8314ACP-EVAL			100 MHz	2.7 GHz									AD8314	Board(s)	RF Log Detector/Controller	AD8314	Board
