MSP430FR2475 Series

Catalog

16 MHZ MCU WITH 32 KB FRAM, 6 KB SRAM, COMPARATOR, 12-BIT ADC, UART/SPI/I2C, TIMER

Part	Program Memory Type	Core Size (Bit Width)	RAM Size Depth	RAM Size Width	Peripherals	Speed	Package Width	Package Name	Package Length	Core Processor	Program Memory Size	Program Memory Depth	Program Memory Width	Package / Case	Mounting Type	Voltage - Supply (Vcc/Vdd) Maximum	Voltage - Supply (Vcc/Vdd) Minimum	Operating Temperature (Max)	Operating Temperature (Min)	Oscillator Type	Connectivity	Number of I/O	A/D Resolution (bits)	Converter Architecture	A/D Channels
Texas Instruments MSP430FR2475TRHBR	FRAM	16 Bit	4 K	8 bit	Brown-out Detect POR PWM Reset WDT	16 MHz	5 mm	32-VQFN	5 mm	MSP430 CPU16	32.5 KB	32.5 K	8 bit	32-VFQFN Exposed Pad	Surface Mount	3.6 V	1.8 V	105 °C	-40 °C	Internal	I2C IrDA SCI SPI UART USART	27	12 bit	SAR	8 count
Texas Instruments MSP430FR2475TRHAT	FRAM	16 Bit	4 K	8 bit	Brown-out Detect POR PWM Reset WDT	16 MHz	6 mm	40-VQFN	6 mm	MSP430 CPU16	32.5 KB	32.5 K	8 bit	40-VFQFN Exposed Pad	Surface Mount	3.6 V	1.8 V	105 °C	-40 °C	Internal	I2C IrDA SCI SPI UART USART	35	12 bit	SAR	10 count
Texas Instruments MSP430FR2475TPTR	FRAM	16 Bit	4 K	8 bit	Brown-out Detect POR PWM Reset WDT	16 MHz	7 mm	48-LQFP	7 mm	MSP430 CPU16	32.5 KB	32.5 K	8 bit	48-LQFP	Surface Mount	3.6 V	1.8 V	105 °C	-40 °C	Internal	I2C IrDA SCI SPI UART USART	43	12 bit	SAR	12 count
Texas Instruments MSP430FR2475TPT	FRAM	16 Bit	4 K	8 bit	Brown-out Detect POR PWM Reset WDT	16 MHz	7 mm	48-LQFP	7 mm	MSP430 CPU16	32.5 KB	32.5 K	8 bit	48-LQFP	Surface Mount	3.6 V	1.8 V	105 °C	-40 °C	Internal	I2C IrDA SCI SPI UART USART	43	12 bit	SAR	12 count
Texas Instruments MSP430FR2475TRHAR	FRAM	16 Bit	4 K	8 bit	Brown-out Detect POR PWM Reset WDT	16 MHz	6 mm	40-VQFN	6 mm	MSP430 CPU16	32.5 KB	32.5 K	8 bit	40-VFQFN Exposed Pad	Surface Mount	3.6 V	1.8 V	105 °C	-40 °C	Internal	I2C IrDA SCI SPI UART USART	35	12 bit	SAR	10 count
Texas Instruments MSP430FR2475TRHBT	FRAM	16 Bit	4 K	8 bit	Brown-out Detect POR PWM Reset WDT	16 MHz	5 mm	32-VQFN	5 mm	MSP430 CPU16	32.5 KB	32.5 K	8 bit	32-VFQFN Exposed Pad	Surface Mount	3.6 V	1.8 V	105 °C	-40 °C	Internal	I2C IrDA SCI SPI UART USART	27	12 bit	SAR	8 count
