TM4C1237H6PGE Series

32-bit Arm Cortex-M4F based MCU with 80-MHz, 256-kb Flash, 32-kb RAM, CAN, RTC, USB, 144-pin LQFP

Catalog

32-bit Arm Cortex-M4F based MCU with 80-MHz, 256-kb Flash, 32-kb RAM, CAN, RTC, USB, 144-pin LQFP

Part	Core Size (Bit Width)	Peripherals	Core Processor	Voltage - Supply (Vcc/Vdd) Maximum	Voltage - Supply (Vcc/Vdd) Minimum	Program Memory Type	Oscillator Type	Connectivity	Program Memory Width	Program Memory Depth	Program Memory Size	A/D Resolution (bits)	A/D Channels	Package / Case	EEPROM Size (Depth)	EEPROM Size (Width)	Mounting Type	Package Length	Package Name	Package Width	Speed	Operating Temperature (Max)	Operating Temperature (Min)	Number of I/O	RAM Size Width	RAM Size Depth
Texas Instruments TM4C1237H6PGEIR	32 Bit	Brown-out Detect DMA POR Reset WDT	ARM® Cortex®-M4F	3.63 V	1.08 V	FLASH	Internal	CANbus I2C IrDA Microwire SPI SSI UART USART USB OTG	8 bit	256 K	256 KB	12 bit	22 count	144-LQFP	2 K	8 bit	Surface Mount	20 mm	144-LQFP	20 mm	80 MHz	85 °C	-40 °C	105	8 bit	32 K

Catalog

32-bit Arm Cortex-M4F based MCU with 80-MHz, 256-kb Flash, 32-kb RAM, CAN, RTC, USB, 144-pin LQFP

Description

The TM4C1237H6PGE microcontroller is targeted for industrial applications, including remote monitoring, electronic point-of-sale machines, test and measurement equipment, network appliances and switches, factory automation, HVAC and building control, gaming equipment, transportation, and fire and security. The TM4C1237H6PGE microcontroller is targeted for industrial applications, including remote monitoring, electronic point-of-sale machines, test and measurement equipment, network appliances and switches, factory automation, HVAC and building control, gaming equipment, transportation, and fire and security.
