AD9683 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

EVAL BOARD 14BIT 250M ADC AD9683

Part	Supplied Contents	Number of A/D Converters	Contents	Sampling Rate (Per Second)	Utilized IC / Part	Number of Bits	Data Interface	Input Voltage (Value)	Power (Typ)	Input Type	Operating Temperature (Min)	Operating Temperature (Max)	Architecture	Voltage - Supply, Digital (Min)	Voltage - Supply, Digital (Max)	Voltage - Supply, Analog (Max)	Voltage - Supply, Analog (Min)	Package / Case	Number of Inputs	Mounting Type	Configuration	Package Length	Package Name	Package Width	Reference Type
Analog Devices Inc./Maxim Integrated AD9683-250EBZ	Board(s)	1 count	Board	250 MHz	AD9683	14 bits	Serial JESD204B SPI™	1.75 Vpp	434 mW
Analog Devices Inc./Maxim Integrated AD9683BCPZRL7-170		1 count		170 MHz		14 bits	JESD204B			Differential	-40 °C	85 °C	Pipelined	1.7 V	1.9 V	1.9 V	1.7 V	32-WFQFN Exposed Pad CSP	1	Surface Mount	ADC	5 mm	32-LFCSP	5 mm	Internal
Analog Devices Inc./Maxim Integrated AD9683BCPZ-250		1 count		250 MHz		14 bits	JESD204B			Differential	-40 °C	85 °C	Pipelined	1.7 V	1.9 V	1.9 V	1.7 V	32-WFQFN Exposed Pad CSP	1	Surface Mount	ADC	5 mm	32-LFCSP	5 mm	Internal
Analog Devices Inc./Maxim Integrated AD9683-170EBZ	Board(s)	1 count	Board	170 MHz	AD9683	14 bits	Serial JESD204B SPI™	1.75 Vpp	365 mW
Analog Devices Inc./Maxim Integrated AD9683BCPZRL7-250		1 count		250 MHz		14 bits	JESD204B			Differential	-40 °C	85 °C	Pipelined	1.7 V	1.9 V	1.9 V	1.7 V	32-WFQFN Exposed Pad CSP	1	Surface Mount	ADC	5 mm	32-LFCSP	5 mm	Internal
Analog Devices Inc./Maxim Integrated AD9683BCPZ-170		1 count		170 MHz		14 bits	JESD204B			Differential	-40 °C	85 °C	Pipelined	1.7 V	1.9 V	1.9 V	1.7 V	32-WFQFN Exposed Pad CSP	1	Surface Mount	ADC	5 mm	32-LFCSP	5 mm	Internal
