MSP430FE4252 Series

Catalog

8-MHZ METERING MCU WITH 2 16-BIT SIGMA-DELTA ADCS, 128-SEGMENT LCD, 16KB FLASH, 512B RAM

Part	Connectivity	Number of I/O	Package Length	Package Name	Package Width	Peripherals	Speed	Program Memory Width	Program Memory Additional Size	Program Memory Depth	Program Memory Size	Mounting Type	RAM Size Depth	RAM Size Width	Core Size (Bit Width)	Operating Temperature (Max)	Operating Temperature (Min)	A/D Channels	A/D Resolution (bits)	Package / Case	Program Memory Type	Voltage - Supply (Vcc/Vdd) Maximum	Voltage - Supply (Vcc/Vdd) Minimum	Core Processor	Oscillator Type
Texas Instruments MSP430FE4252IPM	SPI UART USART	14	10 mm	64-LQFP	10 mm	Brown-out Detect LCD POR PWM Reset WDT	8 MHz	8 bit	256 B	16 K	16 KB	Surface Mount	512	8 bit	16 Bit	85 °C	-40 °C	2 count	16 bit	64-LQFP	FLASH	3.6 V	1.8 V	MSP430 CPU16	Internal
Texas Instruments MSP430FE4252IPMR	SPI UART USART	14	10 mm	64-LQFP	10 mm	Brown-out Detect LCD POR PWM Reset WDT	8 MHz	8 bit	256 B	16 K	16 KB	Surface Mount	512	8 bit	16 Bit	85 °C	-40 °C	2 count	16 bit	64-LQFP	FLASH	3.6 V	1.8 V	MSP430 CPU16	Internal
