DRV10963 Series

Catalog

5-V NOMINAL, 1.8-A PEAK SENSORLESS SINUSOIDAL CONTROL 3-PHASE BLDC MOTOR DRIVER

Part	Motor Type - AC, DC	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Function	Half-Bridge Count	Output Configuration	Interface	Mounting Type	Package Width	Package Name	Package Length	Technology	Current - Output	Voltage - Load (Min)	Voltage - Load (Max)	Applications	Package / Case	Operating Temperature (Max)	Operating Temperature (Min)
Texas Instruments DRV10963JUDSNR	Brushless DC (BLDC)	5.5 V	2.1 V	Control and Power Stage Driver - Fully Integrated	3	Half-Bridge	PWM	Surface Mount	3 mm	10-SON	3 mm	Power MOSFET	500 mA	2.1 V	5.5 V	Fan Motor Driver	10-UFDFN Exposed Pad	125 °C	-40 °C
Texas Instruments DRV10963JADSNT	Brushless DC (BLDC)	5.5 V	2.1 V	Control and Power Stage Driver - Fully Integrated	3	Half-Bridge	PWM	Surface Mount	3 mm	10-SON	3 mm	Power MOSFET	500 mA	2.1 V	5.5 V	Fan Motor Driver	10-UFDFN Exposed Pad	125 °C	-40 °C
Texas Instruments DRV10963PDSNT	Brushless DC (BLDC)	5.5 V	2.1 V	Control and Power Stage Driver - Fully Integrated	3	Half-Bridge	PWM	Surface Mount	3 mm	10-SON	3 mm	Power MOSFET	500 mA	2.1 V	5.5 V	Fan Motor Driver	10-UFDFN Exposed Pad	125 °C	-40 °C
Texas Instruments DRV10963JJDSNR	Brushless DC (BLDC)	5.5 V	2.1 V	Control and Power Stage Driver - Fully Integrated	3	Half-Bridge	PWM	Surface Mount	3 mm	10-SON	3 mm	Power MOSFET	500 mA	2.1 V	5.5 V	Fan Motor Driver	10-UFDFN Exposed Pad	125 °C	-40 °C
Texas Instruments DRV10963JADSNR	Brushless DC (BLDC)	5.5 V	2.1 V	Control and Power Stage Driver - Fully Integrated	3	Half-Bridge	PWM	Surface Mount	3 mm	10-SON	3 mm	Power MOSFET	500 mA	2.1 V	5.5 V	Fan Motor Driver	10-UFDFN Exposed Pad	125 °C	-40 °C
Texas Instruments DRV10963DSNR	Brushless DC (BLDC)	5.5 V	2.1 V	Control and Power Stage Driver - Fully Integrated	3	Half-Bridge	PWM	Surface Mount	3 mm	10-SON	3 mm	Power MOSFET	500 mA	2.1 V	5.5 V	Fan Motor Driver	10-UFDFN Exposed Pad	125 °C	-40 °C
Texas Instruments DRV10963JMDSNR	Brushless DC (BLDC)	5.5 V	2.1 V	Control and Power Stage Driver - Fully Integrated	3	Half-Bridge	PWM	Surface Mount	3 mm	10-SON	3 mm	Power MOSFET	500 mA	2.1 V	5.5 V	Fan Motor Driver	10-UFDFN Exposed Pad	125 °C	-40 °C
Texas Instruments DRV10963JUDSNT	Brushless DC (BLDC)	5.5 V	2.1 V	Control and Power Stage Driver - Fully Integrated	3	Half-Bridge	PWM	Surface Mount	3 mm	10-SON	3 mm	Power MOSFET	500 mA	2.1 V	5.5 V	Fan Motor Driver	10-UFDFN Exposed Pad	125 °C	-40 °C
Texas Instruments DRV10963JMDSNT	Brushless DC (BLDC)	5.5 V	2.1 V	Control and Power Stage Driver - Fully Integrated	3	Half-Bridge	PWM	Surface Mount	3 mm	10-SON	3 mm	Power MOSFET	500 mA	2.1 V	5.5 V	Fan Motor Driver	10-UFDFN Exposed Pad	125 °C	-40 °C
Texas Instruments DRV10963JJDSNT	Brushless DC (BLDC)	5.5 V	2.1 V	Control and Power Stage Driver - Fully Integrated	3	Half-Bridge	PWM	Surface Mount	3 mm	10-SON	3 mm	Power MOSFET	500 mA	2.1 V	5.5 V	Fan Motor Driver	10-UFDFN Exposed Pad	125 °C	-40 °C
