ADC08L060 Series
Manufacturer: Texas Instruments
Beta
⌘K
8-BIT, 60-MSPS, ULTRA-LOW POWER ANALOG-TO-DIGITAL CONVERTER (ADC)
| Part | Architecture | Operating Temperature (Min) | Operating Temperature (Max) | Package Name | Voltage - Supply, Analog (Min) | Voltage - Supply, Analog (Max) | Number of Inputs | Reference Type | Input Type | Data Interface | Number of Bits | Voltage - Supply, Digital (Min) | Voltage - Supply, Digital (Max) | Number of A/D Converters | Configuration | Ratio - ADC | Ratio - S/H | Package Width | Package Length | Mounting Type | Sampling Rate (Per Second) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | Pipelined | -40 °C | 85 °C | 24-TSSOP | 2.4 V | 3.6 V | 1 | External | Single Ended | Parallel | 8 bits | 2.4 V | 3.6 V | 1 count | S/H-ADC | 1 | 1 | 4.4 mm | 0.173 in | Surface Mount | 60 MHz |
Texas Instruments | Pipelined | -40 °C | 85 °C | 24-TSSOP | 2.4 V | 3.6 V | 1 | External | Single Ended | Parallel | 8 bits | 2.4 V | 3.6 V | 1 count | S/H-ADC | 1 | 1 | 4.4 mm | 0.173 in | Surface Mount | 60 MHz |
