ADC12DS080 Series
Manufacturer: Texas Instruments
Beta
⌘K
DUAL-CHANNEL, 12-BIT, 80-MSPS ANALOG-TO-DIGITAL CONVERTER (ADC)
| Part | Reference Type | Voltage - Supply, Analog (Min) | Voltage - Supply, Analog (Max) | Sampling Rate (Per Second) | Number of Inputs | Number of Bits | Mounting Type | Voltage - Supply, Digital (Min) | Voltage - Supply, Digital (Max) | Number of A/D Converters | Input Type | Architecture | Data Interface | Operating Temperature (Min) | Operating Temperature (Max) | Package / Case | Features | Configuration | Package Width | Package Name | Package Length | Ratio - ADC | Ratio - S/H |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | External Internal | 2.7 V | 3.6 V | 80 MHz | 2 | 12 bits | Surface Mount | 2.7 V | 3.6 V | 2 count | Differential | Pipelined | LVDS - Serial | -40 °C | 85 °C | 60-WFQFN Exposed Pad | Simultaneous Sampling | S/H-ADC | 9 mm | 60-WQFN | 9 mm | 1 | 1 |
