PGA2311 Series

Catalog

AUDIO AMP SPEAKER 2-CH STEREO CLASS-AB 16-PIN SOIC T/R

Part	Number of Channels	Operating Temperature (Max)	Operating Temperature (Min)	Package Name	Specifications (Max)	Specifications (Min)	Return Loss	Isolation (Min)	Interface	Grade	Mounting Type	Function	Applications	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Package Length	Package Width
Texas Instruments PGA2311U/1KG4	2	85 °C	-40 °C	16-SOIC	-95.5 dB	31.5 dB	-95.5 dB	31.5 dB	SPI	Automotive	Surface Mount	Volume Control	Audio Musical Instruments	5.25 V	-4.75 V	0.295 in	7.5 mm
Texas Instruments PGA2311PA	2	85 °C	-40 °C	16-DIP 16-PDIP	-95.5 dB	31.5 dB	-95.5 dB	31.5 dB	SPI	Automotive	Through Hole	Volume Control	Audio Musical Instruments	5.25 V	-4.75 V	0.3 in	7.62 mm
Texas Instruments PGA2311U	2	85 °C	-40 °C	16-SOIC	-95.5 dB	31.5 dB	-95.5 dB	31.5 dB	SPI	Automotive	Surface Mount	Volume Control	Audio Musical Instruments	5.25 V	-4.75 V	0.295 in	7.5 mm
Texas Instruments PGA2311P	2	85 °C	-40 °C	16-DIP 16-PDIP	-95.5 dB	31.5 dB	-95.5 dB	31.5 dB	SPI	Automotive	Through Hole	Volume Control	Audio Musical Instruments	5.25 V	-4.75 V	0.3 in	7.62 mm
Texas Instruments PGA2311U/1K	2	85 °C	-40 °C	16-SOIC	-95.5 dB	31.5 dB	-95.5 dB	31.5 dB	SPI	Automotive	Surface Mount	Volume Control	Audio Musical Instruments	5.25 V	-4.75 V	0.295 in	7.5 mm
Texas Instruments PGA2311UA	2	85 °C	-40 °C	16-SOIC	-95.5 dB	31.5 dB	-95.5 dB	31.5 dB	SPI	Automotive	Surface Mount	Volume Control	Audio Musical Instruments	5.25 V	-4.75 V	0.295 in	7.5 mm
Texas Instruments PGA2311PA	2	85 °C	-40 °C	16-DIP 16-PDIP	-95.5 dB	31.5 dB	-95.5 dB	31.5 dB	SPI	Automotive	Through Hole	Volume Control	Audio Musical Instruments	5.25 V	-4.75 V	0.3 in	7.62 mm
Texas Instruments PGA2311UA/1K	2	85 °C	-40 °C	16-SOIC	-95.5 dB	31.5 dB	-95.5 dB	31.5 dB	SPI	Automotive	Surface Mount	Volume Control	Audio Musical Instruments	5.25 V	-4.75 V	0.295 in	7.5 mm
