LMZ23603 Series

Catalog

3A SIMPLE SWITCHER® POWER MODULE WITH 36V MAXIMUM INPUT VOLTAGE

Part	Number of Outputs	Efficiency	Voltage - Output 1 (Min)	Voltage - Output 1 (Max)	Operating Temperature (Max)	Operating Temperature (Min)	Package / Case	Voltage - Input (Min)	Mounting Type	Type	Voltage - Input (Max)	Package Name	Applications	Features	Size / Dimension Width	Size / Dimension Height	Size / Dimension Length	Current - Output (Max)	Board Type	Supplied Contents	Total Output Count	Output Type	Non-Isolated Output Count	Voltage - Output	Main Purpose	Utilized IC / Part	Frequency - Switching	Current - Output	Contents	Regulator Topology	Voltage - Input (Minimum)	Voltage - Input (Maximum)
Texas Instruments LMZ23603TZ/NOPB	1	92 %	800 mV	6 V	125 °C	-40 °C	Power Module TO-PMOD-7	6 V	Surface Mount	Non-Isolated PoL Module	36 V	TO-PMOD-7	ITE (Commercial)	UVLO	0.39 in	0.18 in	0.4 in	3 A
Texas Instruments LMZ23603TZE/NOPB	1	92 %	800 mV	6 V	125 °C	-40 °C	Power Module TO-PMOD-7	6 V	Surface Mount	Non-Isolated PoL Module	36 V	TO-PMOD-7	ITE (Commercial)	UVLO	0.39 in	0.18 in	0.4 in	3 A
Texas Instruments LMZ23603EVAL/NOPB																			Fully Populated	Board(s)	1	Non-Isolated	1 count	3.3 V	DC/DC Step Down	LMZ23603	812 kHz	3 A	Board	Buck	6 V	36 V
Texas Instruments LMZ23603TZX/NOPB	1	92 %	800 mV	6 V	125 °C	-40 °C	Power Module TO-PMOD-7	6 V	Surface Mount	Non-Isolated PoL Module	36 V	TO-PMOD-7	ITE (Commercial)	UVLO	0.39 in	0.18 in	0.4 in	3 A
