DAC714 Series

Catalog

IC DAC 16BIT V-OUT 16SOIC

Part	Package Name	Architecture	Package Length	Package Width	Number of Bits	Operating Temperature (Min)	Operating Temperature (Max)	Settling Time	Voltage - Supply, Analog (Maximum)	Voltage - Supply, Analog (Nominal Positive)	Voltage - Supply, Analog (Nominal Negative)	Number of D/A Converters	Differential Output	Data Interface	Output Type	Mounting Type	INL (Max) (LSB)	DNL (Max) (LSB)	Reference Type
Texas Instruments DAC714U/1KG4	16-SOIC	R-2R	0.295 in	7.5 mm	16 bits	-40 °C	85 °C	10 µs	16.5 V	11.4 V	-11.4 V	1 count	No	SPI	Voltage - Buffered	Surface Mount	8 LSB	8 LSB	Internal
Texas Instruments DAC714U/1K	16-SOIC	R-2R	0.295 in	7.5 mm	16 bits	-40 °C	85 °C	10 µs	16.5 V	11.4 V	-11.4 V	1 count	No	SPI	Voltage - Buffered	Surface Mount	8 LSB	8 LSB	Internal
Texas Instruments DAC714U	16-SOIC	R-2R	0.295 in	7.5 mm	16 bits	-40 °C	85 °C	10 µs	16.5 V	11.4 V	-11.4 V	1 count	No	SPI	Voltage - Buffered	Surface Mount	8 LSB	8 LSB	Internal
Texas Instruments DAC714PG4	16-DIP 16-PDIP	R-2R	0.3 in	7.62 mm	16 bits	-40 °C	85 °C	10 µs	16.5 V	11.4 V	-11.4 V	1 count	No	SPI	Voltage - Buffered	Through Hole	8 LSB	8 LSB	Internal
Texas Instruments DAC714P	16-DIP 16-PDIP	R-2R	0.3 in	7.62 mm	16 bits	-40 °C	85 °C	10 µs	16.5 V	11.4 V	-11.4 V	1 count	No	SPI	Voltage - Buffered	Through Hole	8 LSB	8 LSB	Internal
