LMV7271 Series

Catalog

SINGLE LOW VOLTAGE, PUSH-PULL COMPARATOR

Part	Voltage - Supply (Single) Maximum	Supply Configuration	Voltage - Supply (Dual) Maximum (Magnitude)	Voltage - Supply (Single) Minimum	Voltage - Supply (Dual) Minimum (Magnitude)	Mounting Type	Package Name	PSRR (Typ)	CMRR (Typ)	Type	Propagation Delay (Max)	Current - Quiescent (Max)	Number of Elements	Operating Temperature (Min)	Operating Temperature (Max)	Current - Input Bias (Max)	Voltage - Input Offset (Max)	Output Type	Package / Case
Texas Instruments LMV7271MF	5.5 V	Dual Single	2.75 V	1.8 V	0.9 V	Surface Mount	SOT-23-5	80 dB	78 dB	General Purpose Standard (General Purpose)	2.1 µs	14 µA	1	-40 °C	85 °C	0.01 µA	4 mV	CMOS Push-Pull Rail-to-Rail
Texas Instruments LMV7271MGX/NOPB	5.5 V	Dual Single	2.75 V	1.8 V	0.9 V	Surface Mount	SC-70-5	80 dB	78 dB	General Purpose Standard (General Purpose)	2.1 µs	14 µA	1	-40 °C	85 °C	0.01 µA	4 mV	CMOS Push-Pull Rail-to-Rail	5-TSSOP SC-70-5 SOT-353
Texas Instruments LMV7271MG/NOPB	5.5 V	Dual Single	2.75 V	1.8 V	0.9 V	Surface Mount	SC-70-5	80 dB	78 dB	General Purpose Standard (General Purpose)	2.1 µs	14 µA	1	-40 °C	85 °C	0.01 µA	4 mV	CMOS Push-Pull Rail-to-Rail	5-TSSOP SC-70-5 SOT-353
Texas Instruments LMV7271MFX/NOPB	5.5 V	Dual Single	2.75 V	1.8 V	0.9 V	Surface Mount	SOT-23-5	80 dB	78 dB	Standard (General Purpose)	2.1 µs	14 µA	1	-40 °C	85 °C	0.01 µA	4 mV	CMOS Push-Pull Rail-to-Rail
Texas Instruments LMV7271MG	5.5 V	Dual Single	2.5 V	1.8 V	0.9 V	Surface Mount	SC-70-5	80 dB	78 dB	Standard (General Purpose)	2.1 µs	14 µA	1	-40 °C	85 °C	1000 pA	4 mV	CMOS Push-Pull Rail-to-Rail	5-TSSOP SC-70-5 SOT-353
Texas Instruments LMV7271MF/NOPB	5.5 V	Dual Single	2.75 V	1.8 V	0.9 V	Surface Mount	SOT-23-5	80 dB	78 dB	General Purpose Standard (General Purpose)	2.1 µs	14 µA	1	-40 °C	85 °C	0.01 µA	4 mV	CMOS Push-Pull Rail-to-Rail
Texas Instruments LMV7271MF/NOPB	5.5 V	Dual Single	2.75 V	1.8 V	0.9 V	Surface Mount	SOT-23-5	80 dB	78 dB	General Purpose Standard (General Purpose)	2.1 µs	14 µA	1	-40 °C	85 °C	0.01 µA	4 mV	CMOS Push-Pull Rail-to-Rail
