DAC101S101 Series

Catalog

10-BIT MICRO POWER, RRO DIGITAL-TO-ANALOG CONVERTER

Part	Data Interface	Voltage - Supply, Digital (Min)	Voltage - Supply, Digital (Max)	Number of Bits	Differential Output	Architecture	Package Name	Number of D/A Converters	Output Type	INL (LSB) Tolerance	INL Negative Tolerance (LSB)	DNL Negative Tolerance (LSB)	DNL Positive Tolerance (LSB)	INL Positive Tolerance (LSB)	Reference Type	Settling Time	Package / Case	Operating Temperature (Min)	Operating Temperature (Max)	Mounting Type	Voltage - Supply, Analog (Min)	Voltage - Supply, Analog (Max)	Package Width	Package Length	Supplied Contents	Utilized IC / Part	Contents	Number of DAC's	DAC Type
Texas Instruments DAC101S101CIMKX/NOPB	DSP SPI	2.7 V	5.5 V	10 bits	No	String DAC	SOT-23-THIN	1 count	Voltage - Buffered	0.6 LSB	0.6 LSB	0.05 LSB	0.15 LSB	0.6 LSB	Supply	7.5 µs	SOT-23-6 Thin TSOT-23-6	-40 °C	105 °C	Surface Mount	2.7 V	5.5 V
Texas Instruments DAC101S101CIMK/NOPB	DSP SPI	2.7 V	5.5 V	10 bits	No	String DAC	SOT-23-THIN	1 count	Voltage - Buffered	0.6 LSB	0.6 LSB	0.05 LSB	0.15 LSB	0.6 LSB	Supply	7.5 µs	SOT-23-6 Thin TSOT-23-6	-40 °C	105 °C	Surface Mount	2.7 V	5.5 V
Texas Instruments DAC101S101CIMMX/NOPB	DSP SPI	2.7 V	5.5 V	10 bits	No	String DAC	8-TSSOP 8-MSOP 8-VSSOP	1 count	Voltage - Buffered	0.6 LSB	0.6 LSB	0.05 LSB	0.15 LSB	0.6 LSB	Supply	7.5 µs		-40 °C	105 °C	Surface Mount	2.7 V	5.5 V	3 mm	0.118 in
Texas Instruments DAC101S101CIMM	DSP SPI	2.7 V	5.5 V	10 bits	No	String DAC	8-TSSOP 8-MSOP 8-VSSOP	1 count	Voltage - Buffered	0.6 LSB	0.6 LSB	0.05 LSB	0.15 LSB	0.6 LSB	Supply	7.5 µs		-40 °C	105 °C	Surface Mount	2.7 V	5.5 V	3 mm	0.118 in
Texas Instruments DAC101S101CIMK	DSP SPI	2.7 V	5.5 V	10 bits	No	String DAC	SOT-23-THIN	1 count	Voltage - Buffered	0.6 LSB	0.6 LSB	0.05 LSB	0.15 LSB	0.6 LSB	Supply	7.5 µs	SOT-23-6 Thin TSOT-23-6	-40 °C	105 °C	Surface Mount	2.7 V	5.5 V
Texas Instruments DAC101S101EVAL	DSP MICROWIRE™ QSPI™ Serial SPI™			10 bits												5 µs									Board(s)	DAC101S101	Board	1	Voltage
Texas Instruments DAC101S101CIMM	DSP SPI	2.7 V	5.5 V	10 bits	No	String DAC	8-TSSOP 8-MSOP 8-VSSOP	1 count	Voltage - Buffered	0.6 LSB	0.6 LSB	0.05 LSB	0.15 LSB	0.6 LSB	Supply	7.5 µs		-40 °C	105 °C	Surface Mount	2.7 V	5.5 V	3 mm	0.118 in
Texas Instruments DAC101S101CIMM/NOPB	DSP SPI	2.7 V	5.5 V	10 bits	No	String DAC	8-TSSOP 8-MSOP 8-VSSOP	1 count	Voltage - Buffered	0.6 LSB	0.6 LSB	0.05 LSB	0.15 LSB	0.6 LSB	Supply	7.5 µs		-40 °C	105 °C	Surface Mount	2.7 V	5.5 V	3 mm	0.118 in
