ADC12L063 Series
Manufacturer: Texas Instruments
Beta
⌘K
12-BIT, 62-MSPS ANALOG-TO-DIGITAL CONVERTER (ADC)
| Part | Voltage - Supply, Digital (Max) | Voltage - Supply, Digital (Min) | Operating Temperature (Min) | Operating Temperature (Max) | Number of A/D Converters | Voltage - Supply, Analog (Max) | Voltage - Supply, Analog (Min) | Reference Type | Input Type | Architecture | Package / Case | Number of Inputs | Configuration | Mounting Type | Ratio - ADC | Ratio - S/H | Sampling Rate (Per Second) | Data Interface | Package Width | Package Name | Package Length | Number of Bits |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 3.6 V | 2.5 V | -40 °C | 85 °C | 1 count | 3.6 V | 3 V | External Internal | Differential | Pipelined | 32-LQFP | 1 | S/H-ADC | Surface Mount | 1 | 1 | 62 MHz | Parallel | 7 mm | 32-TQFP | 7 mm | 12 bits |
Texas Instruments | 3.6 V | 2.5 V | -40 °C | 85 °C | 1 count | 3.6 V | 3 V | External Internal | Differential | Pipelined | 32-LQFP | 1 | S/H-ADC | Surface Mount | 1 | 1 | 62 MHz | Parallel | 7 mm | 32-TQFP | 7 mm | 12 bits |
