LMP7709 Series

Catalog

PRECISION, CMOS INPUT, RRIO, WIDE SUPPLY RANGE DECOMPENSATED QUAD AMPLIFIER

Part	Mounting Type	Gain Bandwidth Product	Package Width	Package Name	Package Length	Voltage - Input Offset	Amplifier Type	Output Type	Number of Circuits	Slew Rate	Voltage - Supply Span (Max)	Voltage - Supply Span (Min)	Current - Input Bias	Current - Output / Channel	Current - Supply	Operating Temperature (Max)	Operating Temperature (Min)
Texas Instruments LMP7709MA/NOPB	Surface Mount	15 MHz	3.9 mm	14-SOIC	0.154 in	37 µV	General Purpose	Rail-to-Rail	4	5.9 V/µs	12 V	2.7 V	0.2 pA	86 mA	2.9 mA	125 °C	-40 °C
Texas Instruments LMP7709MTX/NOPB	Surface Mount	15 MHz	4.4 mm	14-TSSOP	0.173 in	37 µV	General Purpose	Rail-to-Rail	4	5.9 V/µs	12 V	2.7 V	0.2 pA	86 mA	2.9 mA	125 °C	-40 °C
Texas Instruments LMP7709MAX/NOPB	Surface Mount	15 MHz	3.9 mm	14-SOIC	0.154 in	37 µV	General Purpose	Rail-to-Rail	4	5.9 V/µs	12 V	2.7 V	0.2 pA	86 mA	2.9 mA	125 °C	-40 °C
Texas Instruments LMP7709MT/NOPB	Surface Mount	15 MHz	4.4 mm	14-TSSOP	0.173 in	37 µV	General Purpose	Rail-to-Rail	4	5.9 V/µs	12 V	2.7 V	0.2 pA	86 mA	2.9 mA	125 °C	-40 °C
