LM3519 Series

Catalog

IC LED DRVR RGLTR PWM TSOT23-6

Part	Voltage - Supply (Max)	Current - Output / Channel	Applications	Operating Temperature (Max)	Operating Temperature (Min)	Voltage - Output	Number of Outputs	Type	Package Name	Mounting Type	Dimming	Frequency	Package / Case	Internal Switch(s)	Topology	Voltage - Supply (Min)	Voltage - Input (Minimum)	Voltage - Input (Maximum)	Contents	Total Output Count	Output Type	Non-Isolated Output Count	Features	Utilized IC / Part
Texas Instruments LM3519MKX-20/NOPB	5.5 V	20 mA	Backlight	85 °C	-40 °C	20 V	1	DC DC Regulator	TSOT-23-6	Surface Mount	PWM	5.4 MHz	SOT-23-6 Thin TSOT-23-6	Yes	Step-Up (Boost)	2.7 V
Texas Instruments LM3519MK-20	5.5 V	20 mA	Backlight	85 °C	-40 °C	20 V	1	DC DC Regulator	TSOT-23-6	Surface Mount	PWM	5.4 MHz	SOT-23-6 Thin TSOT-23-6	Yes	Step-Up (Boost)	2.7 V
Texas Instruments LM3519MKEV		20 mA															2.7 V	5.5 V	Board	1	Non-Isolated	1 count	Dimmable	LM3519
Texas Instruments LM3519MKX-20	5.5 V	20 mA	Backlight	85 °C	-40 °C	20 V	1	DC DC Regulator	TSOT-23-6	Surface Mount	PWM	5.4 MHz	SOT-23-6 Thin TSOT-23-6	Yes	Step-Up (Boost)	2.7 V
Texas Instruments LM3519MK-20/NOPB	5.5 V	20 mA	Backlight	85 °C	-40 °C	20 V	1	DC DC Regulator	TSOT-23-6	Surface Mount	PWM	5.4 MHz	SOT-23-6 Thin TSOT-23-6	Yes	Step-Up (Boost)	2.7 V
Texas Instruments LM3519MK-20/NOPB	5.5 V	20 mA	Backlight	85 °C	-40 °C	20 V	1	DC DC Regulator	TSOT-23-6	Surface Mount	PWM	5.4 MHz	SOT-23-6 Thin TSOT-23-6	Yes	Step-Up (Boost)	2.7 V
