LM2588 Series
Manufacturer: Texas Instruments
Beta
⌘K
IC REG MULT CONFIG 3.3V 5A DDPAK
| Part | Frequency - Switching (Min) | Frequency - Switching (Max) | Package Name | Output Configuration | Number of Outputs | Synchronous Rectifier | Voltage - Input (Min) | Topology | Output Type | Voltage - Output (Min/Fixed) | Current - Output | Function | Package Leads | Operating Temperature (Max) | Operating Temperature (Min) | Mounting Type | Voltage - Input (Max) | Package / Case | Voltage - Output (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 100 kHz | 200 kHz | D2PAK TO-263 (DDPAK-7) | Positive | 1 | No | 4 V | Boost Flyback Forward Converter | Fixed | 3.3 V | 5 A | Step-Up Step-Up/Step-Down | 7 Leads | 125 °C | -40 °C | Surface Mount | 40 V | ||
 Texas Instruments | 100 kHz | 200 kHz | D2PAK TO-263 (DDPAK-7) | Positive | 1 | No | 4 V | Boost Flyback Forward Converter | Fixed | 5 V | 5 A | Step-Up Step-Up/Step-Down | 7 Leads | 125 °C | -40 °C | Surface Mount | 40 V | ||
Texas Instruments | 100 kHz | 200 kHz | D2PAK TO-263 (DDPAK-7) | Positive | 1 | No | 4 V | Boost Flyback Forward Converter | Fixed | 12 V | 5 A | Step-Up Step-Up/Step-Down | 7 Leads | 125 °C | -40 °C | Surface Mount | 40 V | ||
Texas Instruments | 100 kHz | 200 kHz | D2PAK TO-263 (DDPAK-7) | Positive | 1 | No | 4 V | Boost Flyback Forward Converter | Fixed | 5 V | 5 A | Step-Up Step-Up/Step-Down | 7 Leads | 125 °C | -40 °C | Surface Mount | 40 V | ||
Texas Instruments | 100 kHz | 200 kHz | D2PAK TO-263 (DDPAK-7) | Positive | 1 | No | 4 V | Boost Flyback Forward Converter | Fixed | 5 V | 5 A | Step-Up Step-Up/Step-Down | 7 Leads | 125 °C | -40 °C | Surface Mount | 40 V | ||
Texas Instruments | 100 kHz | 200 kHz | D2PAK TO-263 (DDPAK-7) | Positive | 1 | No | 4 V | Boost Flyback Forward Converter | Fixed | 3.3 V | 5 A | Step-Up Step-Up/Step-Down | 7 Leads | 125 °C | -40 °C | Surface Mount | 40 V | ||
 Texas Instruments | 100 kHz | 200 kHz | TO-220-7 | Positive | 1 | No | 4 V | Boost Flyback Forward Converter | Fixed | 12 V | 5 A | Step-Up Step-Up/Step-Down | 125 °C | -40 °C | Through Hole | 40 V | TO-220-7 Formed Leads | ||
 Texas Instruments | 100 kHz | 200 kHz | D2PAK TO-263 (DDPAK-7) | Positive | 1 | No | 4 V | Boost Flyback Forward Converter | Fixed | 5 V | 5 A | Step-Up Step-Up/Step-Down | 7 Leads | 125 °C | -40 °C | Surface Mount | 40 V | ||
 Texas Instruments | 100 kHz | 200 kHz | TO-220-7 | Positive | 1 | No | 4 V | Boost Flyback Forward Converter | Adjustable | 1.23 V | 5 A | Step-Up Step-Up/Step-Down | 125 °C | -40 °C | Through Hole | 40 V | TO-220-7 Formed Leads | 60 V | |
Texas Instruments | 100 kHz | 200 kHz | TO-220-7 | Positive | 1 | No | 4 V | Boost Flyback Forward Converter | Fixed | 3.3 V | 5 A | Step-Up Step-Up/Step-Down | 125 °C | -40 °C | Through Hole | 40 V | TO-220-7 Formed Leads |
