LM26484 Series
Manufacturer: Texas Instruments
Beta
⌘K
BOARD EVALUATION FOR LM2684
| Part | Board Type | Supplied Contents | Non-Isolated Output Count | Output Type | Total Output Count | Regulator Topology | Utilized IC / Part | Main Purpose | Frequency - Switching | Contents | Voltage - Output | Current - Output (Value 1) | Current - Output (Value 2) | Current - Output (Value 3) | Voltage - Input (Minimum) | Voltage - Input (Maximum) | Operating Temperature (Max) | Operating Temperature (Min) | Package Length | Package Name | Package Width | Voltage - Supply (Maximum) | Voltage - Supply (Minimum) | Applications | Package / Case | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | Fully Populated | Board(s) | 3 | Non-Isolated | 3 | Buck | LM26484 | DC/DC Step Down with LDO | 2 MHz | Board | 1 V 1.8 V | 2 A | 2 A | 1 A | 3 V | 5.5 V | ||||||||||
 Texas Instruments | 125 °C | -40 °C | 4 mm | 24-WQFN | 5 mm | 5.5 V | 3 V | Digital Cores | 24-WFQFN Exposed Pad | Surface Mount | ||||||||||||||||
 Texas Instruments | 125 °C | -40 °C | 4 mm | 24-WQFN | 5 mm | 5.5 V | 3 V | Digital Cores | 24-WFQFN Exposed Pad | Surface Mount | ||||||||||||||||
Texas Instruments | 125 °C | -40 °C | 4 mm | 24-WQFN | 5 mm | 5.5 V | 3 V | Digital Cores | 24-WFQFN Exposed Pad | Surface Mount | ||||||||||||||||
Texas Instruments | 125 °C | -40 °C | 4 mm | 24-WQFN | 5 mm | 5.5 V | 3 V | Digital Cores | 24-WFQFN Exposed Pad | Surface Mount |
