LP5990 Series

Catalog

LDO VOLTAGE REGULATORS 200-MA LOW-IQ HIGH -ACCURACY LOW-DROPOU A 926-LP5990TM12NOPB

Part	Output Type	Control Features	Mounting Type	Package / Case	Number of Regulators	Voltage - Output (Min/Fixed)	Current - Quiescent (Iq)	Voltage - Input (Max)	Voltage Dropout (Max)	PSRR	Current - Output	Operating Temperature (Min)	Operating Temperature (Max)	Protection Features	Package Name	Package Length	Package Width	Output Configuration	Supplied Contents	Board Type	Voltage - Output	Contents	Utilized IC / Part	Voltage - Input (Maximum)	Voltage - Input (Minimum)	Channels per IC (Single)	Channels per IC (Type)	Channels per IC (Count)	Regulator Type
Texas Instruments LP5990TMX-1.2/NOPB	Fixed	Enable	Surface Mount	4-WFBGA DSBGA	1	1.2 V	75 µA	5.5 V	0.25 V	55 dB	200 mA	-40 °C	85 °C	Over Current Over Temperature Short Circuit	4-DSBGA	0.9 mm	0.9 mm	Positive
Texas Instruments LP5990TM-2.8EV											200 mA								Board(s)	Fully Populated	2.8 V	Board	LP5990	5.5 V	2.2 V	1	Single	1	Positive Fixed
Texas Instruments LP5990TMX-1.8/NOPB	Fixed	Enable	Surface Mount	4-WFBGA DSBGA	1	1.8 V	75 µA	5.5 V	0.25 V	55 dB	200 mA	-40 °C	85 °C	Over Current Over Temperature Short Circuit	4-DSBGA			Positive
Texas Instruments LP5990TM-1.8/NOPB	Fixed	Enable	Surface Mount	4-WFBGA DSBGA	1	1.8 V	75 µA	5.5 V	0.25 V	55 dB	200 mA	-40 °C	85 °C	Over Current Over Temperature Short Circuit	4-DSBGA			Positive
Texas Instruments LP5990TMX-3.0/NOPB	Fixed	Enable	Surface Mount	4-WFBGA DSBGA	1	3 V	75 µA	5.5 V	0.25 V	55 dB	200 mA	-40 °C	85 °C	Over Current Over Temperature Short Circuit	4-DSBGA			Positive
Texas Instruments LP5990TMX-1.2/NOPB	Fixed	Enable	Surface Mount	4-WFBGA DSBGA	1	1.2 V	75 µA	5.5 V	0.25 V	55 dB	200 mA	-40 °C	85 °C	Over Current Over Temperature Short Circuit	4-DSBGA			Positive
Texas Instruments LP5990TMX-3.3/NOPB	Fixed	Enable	Surface Mount	4-WFBGA DSBGA	1	3.3 V	75 µA	5.5 V	0.25 V	55 dB	200 mA	-40 °C	85 °C	Over Current Over Temperature Short Circuit	4-DSBGA			Positive
Texas Instruments LP5990TM-3.3/NOPB	Fixed	Enable	Surface Mount	4-WFBGA DSBGA	1	3.3 V	75 µA	5.5 V	0.25 V	55 dB	200 mA	-40 °C	85 °C	Over Current Over Temperature Short Circuit	4-DSBGA			Positive
Texas Instruments LP5990TM-3.6/NOPB	Fixed	Enable	Surface Mount	4-WFBGA DSBGA	1	3.6 V	75 µA	5.5 V	0.25 V	55 dB	200 mA	-40 °C	85 °C	Over Current Over Temperature Short Circuit	4-DSBGA	0.9 mm	0.9 mm	Positive
Texas Instruments LP5990TM-3.0/NOPB	Fixed	Enable	Surface Mount	4-WFBGA DSBGA	1	3 V	75 µA	5.5 V	0.25 V	55 dB	200 mA	-40 °C	85 °C	Over Current Over Temperature Short Circuit	4-DSBGA			Positive
