ADC78H90 Series
Manufacturer: Texas Instruments
Beta
⌘K
8-CHANNEL SINGLE ADC SAR 500KSPS 12-BIT SERIAL 16-PIN TSSOP TUBE
| Part | Package Length | Package Name | Package Width | Mounting Type | Reference Type | Data Interface | Configuration | Voltage - Supply, Digital (Min) | Voltage - Supply, Digital (Max) | Number of A/D Converters | Sampling Rate (Per Second) | Ratio - ADC | Ratio - S/H | Number of Bits | Input Type | Architecture | Number of Inputs | Voltage - Supply, Analog (Max) | Voltage - Supply, Analog (Min) | Operating Temperature (Min) | Operating Temperature (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 0.173 in | 16-TSSOP | 4.4 mm | Surface Mount | Supply | DSP SPI | MUX-S/H-ADC | 2.7 V | 5.25 V | 1 count | 500 kHz | 1 | 1 | 12 bits | Single Ended | SAR | 8 | 5.25 V | 2.7 V | -40 °C | 85 °C |
Texas Instruments | 0.173 in | 16-TSSOP | 4.4 mm | Surface Mount | Supply | DSP SPI | MUX-S/H-ADC | 2.7 V | 5.25 V | 1 count | 500 kHz | 1 | 1 | 12 bits | Single Ended | SAR | 8 | 5.25 V | 2.7 V | -40 °C | 85 °C |
