LM95241 Series

Catalog

±1.25°C DUAL REMOTE & LOCAL TEMPERATURE SENSOR WITH BETA COMPENSATION AND SMBUS, I

Part	Features	Mounting Type	Resolution (Remote)	Resolution (Local)	Accuracy - Highest (Lowest)	Operating Temperature (Max)	Operating Temperature (Min)	Sensing Temperature - Remote (Min)	Sensing Temperature - Remote (Max)	Output Type	Package Width	Package Name	Package Length	Test Condition (Max)	Test Condition (Min)	Sensing Temperature - Local (Min)	Sensing Temperature - Local (Max)	Sensor Type	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Supplied Contents	Sensitivity Tolerance	Sensing Range (Max)	Sensing Range (Min)	Embedded	Contents	Utilized IC / Part	Interface
Texas Instruments LM95241CIMM-2/NOPB	One-Shot Programmable Resolution Shutdown Mode Standby Mode	Surface Mount	12 b	10 b	3 °C	125 °C	0 °C	0 °C	85 °C	SMBus	3 mm	8-TSSOP 8-MSOP 8-VSSOP	0.118 in	85 °C	0 °C	0 °C	85 °C	Digital Local/Remote	3.6 V	3 V
Texas Instruments LM95241CIMMX-2/NOPB	One-Shot Programmable Resolution Shutdown Mode Standby Mode	Surface Mount	12 b	10 b	3 °C	125 °C	0 °C	0 °C	85 °C	SMBus	3 mm	8-TSSOP 8-MSOP 8-VSSOP	0.118 in	85 °C	0 °C	0 °C	85 °C	Digital Local/Remote	3.6 V	3 V
Texas Instruments LM95241CIMM-2	One-Shot Programmable Resolution Shutdown Mode Standby Mode	Surface Mount	12 b	10 b	3 °C	125 °C	0 °C	0 °C	85 °C	SMBus	3 mm	8-TSSOP 8-MSOP 8-VSSOP	0.118 in	85 °C	0 °C	0 °C	85 °C	Digital Local/Remote	3.6 V	3 V
Texas Instruments LM95241CIMM-1/NOPB	One-Shot Programmable Resolution Shutdown Mode Standby Mode	Surface Mount	12 b	10 b	3 °C	125 °C	0 °C	0 °C	85 °C	SMBus	3 mm	8-TSSOP 8-MSOP 8-VSSOP	0.118 in	85 °C	0 °C	0 °C	85 °C	Digital Local/Remote	3.6 V	3 V
Texas Instruments LM95241CIMMX-1/NOPB	One-Shot Programmable Resolution Shutdown Mode Standby Mode	Surface Mount	12 b	10 b	3 °C	125 °C	0 °C	0 °C	85 °C	SMBus	3 mm	8-TSSOP 8-MSOP 8-VSSOP	0.118 in	85 °C	0 °C	0 °C	85 °C	Digital Local/Remote	3.6 V	3 V
Texas Instruments LM95241CIMM-2/NOPB	One-Shot Programmable Resolution Shutdown Mode Standby Mode	Surface Mount	12 b	10 b	3 °C	125 °C	0 °C	0 °C	85 °C	SMBus	3 mm	8-TSSOP 8-MSOP 8-VSSOP	0.118 in	85 °C	0 °C	0 °C	85 °C	Digital Local/Remote	3.6 V	3 V
Texas Instruments LM95241CIMMX/NOPB	One-Shot Programmable Resolution Shutdown Mode Standby Mode	Surface Mount	12 b	10 b	3 °C	125 °C	0 °C	0 °C	85 °C	SMBus	3 mm	8-TSSOP 8-MSOP 8-VSSOP	0.118 in	85 °C	0 °C	0 °C	85 °C	Digital Local/Remote	3.6 V	3 V
Texas Instruments LM95241CIMMX-2	One-Shot Programmable Resolution Shutdown Mode Standby Mode	Surface Mount	12 b	10 b	3 °C	125 °C	0 °C	0 °C	85 °C	SMBus	3 mm	8-TSSOP 8-MSOP 8-VSSOP	0.118 in	85 °C	0 °C	0 °C	85 °C	Digital Local/Remote	3.6 V	3 V
Texas Instruments LM95241EB																		Temperature	3.6 V	3 V	Board(s)	1 °C	140 °C	0 °C	No	Board	LM95241	SMBus (2-Wire/I2C)
Texas Instruments LM95241CIMM-1	One-Shot Programmable Resolution Shutdown Mode Standby Mode	Surface Mount	12 b	10 b	3 °C	125 °C	0 °C	0 °C	85 °C	SMBus	3 mm	8-TSSOP 8-MSOP 8-VSSOP	0.118 in	85 °C	0 °C	0 °C	85 °C	Digital Local/Remote	3.6 V	3 V
