CD54HCT393 Series

High Speed CMOS Logic Dual 4-Stage Binary Counter

Catalog

High Speed CMOS Logic Dual 4-Stage Binary Counter

Part	Trigger Type	Direction	Mounting Type	Package Length	Package Name	Package Width	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Logic Type	Number of Elements	Operating Temperature (Max)	Operating Temperature (Min)	Number of Bits per Element	Reset	Count Rate
Texas Instruments CD54HCT393F	Negative Edge	Up	Through Hole	0.3 in	14-CDIP	7.62 mm	5.5 V	4.5 V	Binary Counter	2	125 °C	-55 °C	4 bits	Asynchronous	27 MHz
Texas Instruments CD54HCT393F3A	Negative Edge	Up	Through Hole	0.3 in	14-CDIP	7.62 mm	5.5 V	4.5 V	Binary Counter	2	125 °C	-55 °C	4 bits	Asynchronous	27 MHz

High Speed CMOS Logic Dual 4-Stage Binary Counter
