ADC14L020 Series
Manufacturer: Texas Instruments
Beta
⌘K
14-BIT, 20-MSPS ANALOG-TO-DIGITAL CONVERTER (ADC)
| Part | Sampling Rate (Per Second) | Mounting Type | Reference Type | Number of Inputs | Package Width | Package Name | Package Length | Voltage - Supply, Analog (Max) | Voltage - Supply, Analog (Min) | Configuration | Architecture | Operating Temperature (Min) | Operating Temperature (Max) | Number of A/D Converters | Ratio - ADC | Ratio - S/H | Package / Case | Input Type | Number of Bits | Data Interface | Voltage - Supply, Digital (Min) | Voltage - Supply, Digital (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 20 MHz | Surface Mount | External Internal | 1 | 7 mm | 32-TQFP | 7 mm | 3.6 V | 3 V | S/H-ADC | Pipelined | -40 °C | 85 °C | 1 count | 1 | 1 | 32-LQFP | Differential | 14 bits | Parallel | 3 V | 3.6 V |
Texas Instruments | 20 MHz | Surface Mount | External Internal | 1 | 7 mm | 32-TQFP | 7 mm | 3.6 V | 3 V | S/H-ADC | Pipelined | -40 °C | 85 °C | 1 count | 1 | 1 | 32-LQFP | Differential | 14 bits | Parallel | 3 V | 3.6 V |
