LM2703 Series
Manufacturer: Texas Instruments
Beta
⌘K
IC LED DRVR RGLTR 350MA SOT23-5
| Part | Mounting Type | Voltage - Supply (Min) | Internal Switch(s) | Number of Outputs | Operating Temperature (Max) | Operating Temperature (Min) | Voltage - Output | Applications | Topology | Type | Current - Output / Channel | Voltage - Supply (Max) | Package Name | Total Output Count | Output Type | Non-Isolated Output Count | Supplied Contents | Board Type | Voltage - Input (Maximum) | Voltage - Input (Minimum) | Regulator Topology | Contents | Main Purpose | Utilized IC / Part |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | Surface Mount | 2.2 V | Yes | 1 | 125 °C | -40 °C | 21 V | Backlight | Step-Up (Boost) | DC DC Regulator | 350 mA | 7 V | SOT-23-5 | |||||||||||
 Texas Instruments | Surface Mount | 2.2 V | Yes | 1 | 125 °C | -40 °C | 21 V | Backlight | Step-Up (Boost) | DC DC Regulator | 350 mA | 7 V | SOT-23-5 | |||||||||||
 Texas Instruments | Surface Mount | 2.2 V | Yes | 1 | 125 °C | -40 °C | 21 V | Backlight | Step-Up (Boost) | DC DC Regulator | 350 mA | 7 V | SOT-23-5 | |||||||||||
Texas Instruments | Surface Mount | 2.2 V | Yes | 1 | 125 °C | -40 °C | 21 V | Backlight | Step-Up (Boost) | DC DC Regulator | 350 mA | 7 V | SOT-23-5 | |||||||||||
Texas Instruments | ||||||||||||||||||||||||
 Texas Instruments | 1 | Non-Isolated | 1 count | Board(s) | Fully Populated | 7 V | 2.2 V | Boost | Board | DC/DC Step Up | LM2703 | |||||||||||||
 Texas Instruments | Surface Mount | 2.2 V | Yes | 1 | 125 °C | -40 °C | 21 V | Backlight | Step-Up (Boost) | DC DC Regulator | 350 mA | 7 V | SOT-23-5 |
