DRV8842 Series

Catalog

47-V, 5-A BRUSHED DC OR HALF-BIPOLAR STEPPER MOTOR DRIVER WITH PWM CONTROL

Part	Function	Package Width	Package Name	Package Length	Technology	Current - Output	Voltage - Load (Min)	Voltage - Load (Max)	Motor Type - Stepper	Applications	Motor Type - AC, DC	Mounting Type	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Half-Bridge Count	Output Configuration	Interface	Operating Temperature (Min)	Operating Temperature (Max)	Primary Attributes	Primary Attributes (Min)	Primary Attributes (Max)	Voltage (Min)	Current	Voltage (Max)	Supplied Contents	Type	Secondary Attributes	Contents	Utilized IC / Part	Embedded Bit Width	Embedded
Texas Instruments DRV8842MPWPREP	Control and Power Stage Driver - Fully Integrated	4.4 mm	28-HTSSOP 28-PowerTSSOP	0.173 in	Power MOSFET	3.5 A	8.2 V	45 V	Bipolar	General Purpose	Brushed DC	Surface Mount	45 V	8.2 V	2	Half Bridge	Parallel	-55 °C	125 °C
Texas Instruments DRV8842PWPR	Control and Power Stage Driver - Fully Integrated	4.4 mm	28-HTSSOP 28-PowerTSSOP	0.173 in	Power MOSFET	3.5 A	8.2 V	45 V	Bipolar	General Purpose	Brushed DC	Surface Mount	45 V	8.2 V	2	Half Bridge	Parallel	-40 °C	150 °C
Texas Instruments DRV8842EVM	Driver Motor Controller																			3.5A (5A Peak) 5A Peak 8.2V ~ 45V Single-H-Bridge Driver	8.2 V	45 V	8.2 V	3.5 A	45 V	Board(s)	Power Management	Graphical User Interface (GUI)	Board	DRV8842	16 bit	MCU Yes
Texas Instruments DRV8842PWP	Control and Power Stage Driver - Fully Integrated	4.4 mm	28-HTSSOP 28-PowerTSSOP	0.173 in	Power MOSFET	3.5 A	8.2 V	45 V	Bipolar	General Purpose	Brushed DC	Surface Mount	45 V	8.2 V	2	Half Bridge	Parallel	-40 °C	150 °C
