THS4532 Series
Manufacturer: Texas Instruments
Beta
⌘K
EVALUATION BOARD THS4532
| Part | Current - Supply (Main IC) | Supplied Contents | Board Type | -3db Bandwidth | Current - Output / Channel | Contents | Slew Rate | Output Type | Amplifier Type | Voltage - Supply (Single) Maximum | Supply Configuration | Voltage - Supply (Dual) Maximum (Magnitude) | Voltage - Supply (Dual) Minimum (Magnitude) | Voltage - Supply (Single) Minimum | Gain Bandwidth Product | Utilized IC / Part | Channels per IC (Dual) | Channels per IC (Type) | Channels per IC (Count) | Voltage - Supply Span (Max) | Number of Circuits | Voltage - Input Offset | Mounting Type | Voltage - Supply Span (Min) | Package Name | Current - Input Bias | Current - Supply | Operating Temperature (Max) | Operating Temperature (Min) | Package Length | Package Width |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 0.00025 µA | Board(s) | Fully Populated | 36 MHz | 25 mA | Board | 390 V/µs | Differential Rail-to-Rail | Differential | 5.5 V | Dual Single | 2.75 V | 1.25 V | 2.5 V | 27 MHz | THS4532 | 2 | Dual | 2 | ||||||||||||
 Texas Instruments | 36 MHz | 25 mA | 390 V/µs | Differential Rail-to-Rail | Differential | 27 MHz | 5.5 V | 2 | 80 µV | Surface Mount | 2.5 V | 16-TSSOP | 200 nA | 250 µA | 125 °C | -40 °C | 0.173 in | 4.4 mm |
