LP38851 Series

Catalog

800-MA, LOW-VIN (0.915-V), ADJUSTABLE ULTRA-LOW-DROPOUT VOLTAGE REGULATOR WITH ENABLE

Part	Protection Features	Output Configuration	Control Features	Current - Output	Voltage - Input (Max)	Operating Temperature (Max)	Operating Temperature (Min)	Voltage Dropout (Max)	PSRR (Minimum)	PSRR (Maximum)	Voltage - Output (Min/Fixed)	Current - Supply (Max)	Package Leads	Package Name	Number of Regulators	Current - Quiescent (Iq)	Voltage - Output (Max)	Output Type	Mounting Type	Package / Case	Package Width	Package Length
Texas Instruments LP38851SX-ADJ/NOPB	Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO)	Positive	Enable Soft Start	800 mA	5.5 V	125 °C	-40 °C	0.2 V	61 dB	72 dB	0.8 V	9 mA	7 Leads	D2PAK TO-263 (DDPAK-7)	1	300 µA	1.8 V	Adjustable	Surface Mount
Texas Instruments LP38851T-ADJ	Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO)	Positive	Enable Soft Start	800 mA	5.5 V	125 °C	-40 °C	0.2 V	61 dB	72 dB	0.8 V	9 mA		TO-220-7	1	300 µA	1.8 V	Adjustable	Through Hole	TO-220-7 Formed Leads
Texas Instruments LP38851MR-ADJ/NOPB	Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO)	Positive	Enable Soft Start	800 mA	5.5 V	125 °C	-40 °C	0.2 V	61 dB	72 dB	0.8 V	9 mA		8-PowerSOIC 8-SO PowerPad	1	300 µA	1.8 V	Adjustable	Surface Mount		3.9 mm	0.154 in
Texas Instruments LP38851MRX-ADJ/NOPB	Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO)	Positive	Enable Soft Start	800 mA	5.5 V	125 °C	-40 °C	0.2 V	61 dB	72 dB	0.8 V	9 mA		8-PowerSOIC 8-SO PowerPad	1	300 µA	1.8 V	Adjustable	Surface Mount		3.9 mm	0.154 in
Texas Instruments LP38851S-ADJ/NOPB	Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO)	Positive	Enable Soft Start	800 mA	5.5 V	125 °C	-40 °C	0.2 V	61 dB	72 dB	0.8 V	9 mA	7 Leads	D2PAK TO-263 (DDPAK-7)	1	300 µA	1.8 V	Adjustable	Surface Mount
Texas Instruments LP38851SX-ADJ	Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO)	Positive	Enable Soft Start	800 mA	5.5 V	125 °C	-40 °C	0.2 V	61 dB	72 dB	0.8 V	9 mA	7 Leads	D2PAK TO-263 (DDPAK-7)	1	300 µA	1.8 V	Adjustable	Surface Mount
Texas Instruments LP38851S-ADJ	Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO)	Positive	Enable Soft Start	800 mA	5.5 V	125 °C	-40 °C	0.2 V	61 dB	72 dB	0.8 V	9 mA	7 Leads	D2PAK TO-263 (DDPAK-7)	1	300 µA	1.8 V	Adjustable	Surface Mount
Texas Instruments LP38851T-ADJ/NOPB	Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO)	Positive	Enable Soft Start	800 mA	5.5 V	125 °C	-40 °C	0.2 V	61 dB	72 dB	0.8 V	9 mA		TO-220-7	1	300 µA	1.8 V	Adjustable	Through Hole	TO-220-7 Formed Leads
