LM2931 Series

Catalog

IC REG LIN 5V 100MA DDPAK/TO263

Part	Current - Output	Package Name	Protection Features	Voltage - Input (Max)	Operating Temperature (Min)	Operating Temperature (Max)	PSRR	Voltage - Output (Min/Fixed)	Number of Regulators	Mounting Type	Output Type	Package / Case	Voltage Dropout (Max)	Output Configuration	Current - Supply (Max)	Current - Quiescent (Iq)	Package Length	Package Width	Package Leads	Voltage - Output (Max)
Texas Instruments LM2931SX-5.0	100 mA	TO-263 (DDPAK-3)	Over Temperature Reverse Polarity Short Circuit	26 V	-40 °C	85 °C	55 dB	5 V	1	Surface Mount	Fixed	D2PAK (3 Leads + Tab) TO-263-4 TO-263AA	0.3 V	Positive	15 mA	1 mA
Texas Instruments LM2931AS-5.0	100 mA	TO-263 (DDPAK-3)	Over Temperature Reverse Polarity Short Circuit	26 V	-40 °C	85 °C	80 dB	5 V	1	Surface Mount	Fixed	D2PAK (3 Leads + Tab) TO-263-4 TO-263AA	0.3 V	Positive	30 mA	15 mA
Texas Instruments LM2931MX-5.0/NOPB	100 mA	8-SOIC	Over Temperature Reverse Polarity Short Circuit	26 V	-40 °C	85 °C	55 dB	5 V	1	Surface Mount	Fixed		0.3 V	Positive	15 mA	1 mA	0.154 in	3.9 mm
Texas Instruments LM2931AZ-5.0/LFT1	100 mA	TO-92-3	Over Temperature Reverse Polarity Short Circuit	26 V	-40 °C	85 °C	80 dB	5 V	1	Through Hole	Fixed	TO-226-3 TO-92-3 (TO-226AA)	0.3 V	Positive	30 mA	15 mA
Texas Instruments LM2931AZ-5.0/NOPB	100 mA	TO-92-3	Over Temperature Reverse Polarity Short Circuit	26 V	-40 °C	85 °C	80 dB	5 V	1	Through Hole	Fixed	TO-226-3 TO-92-3 (TO-226AA)	0.3 V	Positive	30 mA	15 mA
Texas Instruments LM2931AM-5.0	100 mA	8-SOIC	Over Temperature Reverse Polarity Short Circuit	26 V	-40 °C	85 °C	80 dB	5 V	1	Surface Mount	Fixed		0.3 V	Positive	30 mA	15 mA	0.154 in	3.9 mm
Texas Instruments LM2931S-5.0	100 mA	DDPAK/TO-263-3	Over Temperature Reverse Polarity Short Circuit	26 V	-40 °C	85 °C	55 dB	5 V	1	Surface Mount	Fixed	D2PAK (3 Leads + Tab) TO-263-4 TO-263AA	0.3 V	Positive	15 mA	1 mA
Texas Instruments LM2931S-5.0/NOPB	100 mA	TO-263 (DDPAK-3)	Over Temperature Reverse Polarity Short Circuit	26 V	-40 °C	85 °C	55 dB	5 V	1	Surface Mount	Fixed	D2PAK (3 Leads + Tab) TO-263-4 TO-263AA	0.3 V	Positive	15 mA	1 mA
Texas Instruments LM2931CS	100 mA	D2PAK TO-263 (DDPAK-5)	Over Temperature Reverse Polarity Short Circuit	26 V	-40 °C	85 °C	55 dB	3 V	1	Surface Mount	Adjustable		0.3 V	Positive	15 mA	1 mA			5 Leads	24 V
Texas Instruments LM2931CT/LF03	100 mA	TO-220-3	Over Temperature Reverse Polarity Short Circuit	26 V	-40 °C	85 °C	55 dB	3 V	1	Through Hole	Adjustable	TO-220-3	0.3 V	Positive	15 mA	1 mA				24 V
