N-channel 80 V 8.7 mΩ standard level MOSFET in D2PAK
N-channel 80 V 8.7 mΩ standard level MOSFET in D2PAK
| Part | Drain to Source Voltage (Vdss) | Mounting Type | Package / Case | FET Type | Power Dissipation (Max) | Drive Voltage (Max Rds On, Min Rds On) | Rds On (Max) | Vgs(th) (Max) | Package Name | Gate Charge (Max) | Current - Continuous Drain (Id) (Tc) | Vgs (Max) | Input Capacitance (Ciss) (Max) | Operating Temperature (Min) | Operating Temperature (Max) | Technology | Current - Continuous Drain (Id) (Tj) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Nexperia USA Inc. | 80 V | Through Hole | TO-220-3 | N-Channel | 170 W | 10 V | 8.7 mOhm | 4 V | TO-220AB | 52 nC | 90 A | 20 V | 3346 pF | -55 °C | 175 °C | MOSFET (Metal Oxide) | |
Nexperia USA Inc. | 80 V | Surface Mount | D2PAK (2 Leads + Tab) TO-263-3 TO-263AB | N-Channel | 170 W | 10 V | 8.7 mOhm | 4 V | D2PAK | 52 nC | 90 A | 20 V | 3346 pF | -55 °C | 175 °C | MOSFET (Metal Oxide) | |
 Nexperia USA Inc. | 90 A |
