OPA2673 Series

Catalog

DUAL, WIDEBAND, HIGH OUTPUT CURRENT AMPLIFIER AND PLC LINE DRIVER WITH ACTIVE OFF-LINE CONTROL

Part	Gain Bandwidth Product	Current - Output / Channel	Voltage - Supply Span (Min)	Operating Temperature (Min)	Operating Temperature (Max)	Amplifier Type	Voltage - Input Offset	Slew Rate	-3db Bandwidth	Current - Input Bias	Package Width	Package Name	Package Length	Mounting Type	Number of Circuits	Package / Case	Voltage - Supply Span (Max)	Current - Supply
Texas Instruments OPA2673IRGVT	600 MHz	700 mA	7 V	-40 °C	85 °C	Current Feedback	2 mV	3500 V/µs	600 MHz	6 µA	4 mm	16-VQFN	4 mm	Surface Mount	2	16-VQFN Exposed Pad	13 V	32 mA
Texas Instruments OPA2673IRGVR	600 MHz	700 mA	7 V	-40 °C	85 °C	Current Feedback	2 mV	3500 V/µs	600 MHz	6 µA	4 mm	16-VQFN	4 mm	Surface Mount	2	16-VQFN Exposed Pad	13 V	32 mA
